Cisco QSFP-H40G-CU1M | 40G QSFP+ DAC Cable, 1m, Passive, Beige Pull Tab
SKU:QSFP-H40G-CU1M
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This passive 40GBASE-CR4 direct-attach copper cable has a QSFP+ connector on each end and carries 40 Gigabit Ethernet over a 1 m run. It is designed for short-reach links between Cisco switches, routers and servers, such as top-of-rack and adjacent-rack connections in data centres, high-performance computing and enterprise core and distribution uplinks.
The cable is a passive twinax assembly with no active electronics, so there is no separate power supply and no onboard signal processing. It uses 30 AWG cable with a black PVC jacket and a beige pull tab, and it is compliant with IEEE 802.3ba and the QSFP+ MSA SFF-8436. It is a straight 40G-to-40G cable, not a breakout cable, and no licence or subscription is required.
It works with Cisco switches and routers that have 40G QSFP/QSFP+ ports, including Nexus 3000, 5600 and 6000 platforms and UCS platforms. Exact platform and software support can be checked in the Cisco Optics-to-Device Compatibility Matrix. Other lengths in the same passive family are 0.5, 2, 3, 4 and 5 m (QSFP-H40G-CU0-5M, QSFP-H40G-CU2M, QSFP-H40G-CU3M, QSFP-H40G-CU4M, QSFP-H40G-CU5M).
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hot-swappable input/output device that plugs into a 40 Gigabit Ethernet Cisco QSFP port
- Interoperable with other IEEE-compliant 40GBASE interfaces where applicable
- Certified and tested on Cisco QSFP 40G ports for performance, quality and reliability
- High-speed electrical interface compliant with IEEE 802.3ba
- QSFP form factor and 2-wire I2C interface compliant with SFF-8436 and the QSFP MSA
- Passive design needs no onboard signal processing, which keeps power draw low
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Product type: Direct attach cable (DAC), QSFP+ to QSFP+
- Standard: 40GBASE-CR4
- Design: Passive, no active electronics
- Connector type: QSFP+ on both ends
- Cable length: 1 m
- Pull tab colour: Beige
- Cable gauge: 30 AWG
- QSFP end cable diameter: 7 mm
- QSFP end bend radius: 50 mm
- QSFP end face plate distance: 100 mm
- Jacket material: PVC
- Jacket colour: Black
- Operating temperature: 0 to 70 C (32 to 158 F)
- Storage temperature: -40 to 85 C (-40 to 185 F)
- Standards: IEEE 802.3ba, QSFP+ MSA SFF-8436
- Safety: Cable jacket UL E116441 compliant, ELV compliant, RoHS 6
FAQs
Q: Does this cable need a licence or subscription?
A: No. It is a passive copper cable and requires no licence or subscription.
Q: Does it need a separate power supply?
A: No. It is a passive cable with no separate power supply and no active electronics.
Q: Which Cisco platforms is it supported on?
A: It works with Cisco switches and routers that have 40G QSFP/QSFP+ ports, including Nexus 3000, 5600 and 6000 and UCS platforms. For exact platform and software support, check the Cisco Optics-to-Device Compatibility Matrix.
Q: Is this a breakout cable?
A: No. It is a straight 40G QSFP+ to 40G QSFP+ cable, so it links one 40G port to another 40G port.
Q: What other lengths are available in this cable family?
A: The passive family also includes 0.5, 2, 3, 4 and 5 m cables (QSFP-H40G-CU0-5M, QSFP-H40G-CU2M, QSFP-H40G-CU3M, QSFP-H40G-CU4M, QSFP-H40G-CU5M). Longer 7 and 10 m runs use the active cables QSFP-H40G-ACU7M and QSFP-H40G-ACU10M.
