Cisco QSFP-H40G-CU0-5M | 40G QSFP+ DAC Cable, Passive, 0.5m, Beige Tab
SKU:QSFP-H40G-CU0-5M
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This is a passive twinax copper direct-attach cable with a QSFP+ connector on each end, providing a 40GBASE-CR4 link of 0.5 m. It is built for very short, low-cost 40 Gigabit Ethernet connections between QSFP ports on switches within a rack or across adjacent racks, such as top-of-rack to aggregation or switch-to-switch links in a data centre.
The cable carries 40 Gbps across four 10G lanes using 30 AWG copper with a black PVC jacket. As a passive assembly it has no active electronics and needs no licence or subscription. The QSFP+ ends use a beige pull tab, which identifies the 0.5 m passive variant among its sibling lengths. The QSFP+ connector is a QSFP+ MSA form factor with a 2-wire I2C interface, and the cable is IEEE 802.3ba compliant.
It is intended for QSFP/QSFP+ 40G ports on Cisco switches, including Nexus series and other 40G QSFP platforms. Check the Cisco Transceiver Module Compatibility Matrix for exact platform and software support before ordering.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Cost-effective 40-gigabit link between QSFP ports on switches within a rack and across adjacent racks
- High-speed electrical interface compliant with IEEE 802.3ba
- QSFP form factor with 2-wire I2C interface and low-speed electrical interfaces compliant with SFF-8436 and the QSFP MSA
- Passive design with no active electronics in the cable assembly
- Part of a range offered in 0.5, 1, 2, 3, 4 and 5 m passive lengths, with active versions in 7 and 10 m
- 30 AWG twinax copper with a black PVC jacket
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Product type: 40GBASE-CR4 QSFP+ to QSFP+ direct-attach copper cable
- Cable length: 0.5 m
- Data rate: 40 Gbps (4 x 10G lanes)
- Cable type: Passive twinax copper
- Connector (both ends): QSFP+
- Pull tab colour: Beige
- AWG: 30
- Jacket material: PVC
- Jacket colour: Black
- QSFP end cable diameter: 7 mm
- QSFP end bend radius: 50 mm
- QSFP end face plate distance: 100 mm
- QSFP connector module max outer dimensions (H x W x D): 13.5 x 18.4 x 72.4 mm
- QSFP connector module weight: 100 g or less (typical)
- Operating temperature: 0 to 70 C (32 to 158 F)
- Storage temperature: -40 to 85 C (-40 to 185 F)
- Standards: IEEE 802.3ba, QSFP+ MSA SFF-8436, SFP+ MSA SFF-8431/8461, RoHS 6
- Safety: Cable jacket UL E116441 compliant, ELV compliant
FAQs
Q: Does this cable need a licence or subscription?
A: No. It is a passive copper cable with no active electronics, so no licence or subscription is required.
Q: Does it need external power?
A: No. It is a passive direct-attach cable and draws its signal power from the host QSFP+ ports on each end.
Q: Which ports and devices does it work with?
A: It connects QSFP/QSFP+ 40G ports on Cisco switches, including Nexus series and other 40G QSFP platforms, for 40GBASE-CR4 links. Check the Cisco Transceiver Module Compatibility Matrix for exact platform and software support.
Q: How does this SKU differ from the other lengths in the range?
A: This SKU is the 0.5 m passive version with a beige pull tab. The same passive range is also offered in 1, 2, 3, 4 and 5 m lengths, with active versions in 7 and 10 m.
Q: How far can this cable reach?
A: The cable is 0.5 m long, designed for very short connections within a rack or between adjacent racks.
