Cisco

Cisco QSFP-H40G-AOC30M | 40G QSFP+ Active Optical Cable, 30m, Green Pull Tab

SKU:QSFP-H40G-AOC30M

$1,270.00 USD
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

Condition
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The QSFP-H40G-AOC30M is a 30 metre 40 Gigabit Ethernet active optical cable with QSFP+ connectors fixed at both ends. It is built for short-reach 40G links in data centres, high-performance computing networks, enterprise core and distribution layers, and service provider environments.

The assembly uses 850 nm multimode optics and a hot-swappable QSFP+ form factor, with a green pull tab and an orange PVC jacket. It needs no separate power supply and draws power from the host QSFP port. The electrical interface complies with IEEE 802.3ba, and the module follows the QSFP MSA and SFF-8436. Link bit error rate is better than 1E-15, and the commercial operating range is 0 to 70 C.

It is supported on Cisco switches and routers with 40G QSFP ports. Check the Cisco Optics-to-Device Compatibility Matrix for your specific platform and software version.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swappable input/output device that plugs into a 40 Gigabit Ethernet QSFP port
- Interoperable with other IEEE-compliant 40GBASE interfaces where applicable
- Certified and tested on Cisco QSFP 40G ports for performance, quality and reliability
- High-speed electrical interface compliant with IEEE 802.3ba
- QSFP form factor with 2-wire I2C interface compliant with SFF-8436 and the QSFP MSA
- Powered from the host port with no separate power supply

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Type: Active optical cable assembly, QSFP+ to QSFP+
- Data rate: 40 Gigabit Ethernet (40GBASE)
- Cable length: 30 m
- Wavelength: 850 nm (multimode)
- Pull tab colour: Green
- Jacket material: PVC
- Jacket colour: Orange
- Cable diameter at QSFP end: 3.5 mm
- Bend radius at QSFP end: 60 mm
- Face plate distance at QSFP end: 115 mm
- Module maximum outer dimensions (H x W x D): 13.5 x 18.4 x 72.4 mm
- Connector module weight: typically 100 g or less
- Operating temperature: 0 to 70 C (32 to 158 F)
- Storage temperature: -40 to 85 C (-40 to 185 F)
- Link BER: better than 1E-15
- Standards: IEEE 802.3ba electrical interface, QSFP MSA, SFF-8436

FAQs

Q: Does this cable need a separate power supply?
A: No. It is powered from the host QSFP port, so no external power is required.

Q: Which devices does it work with?
A: It is supported on Cisco switches and routers with 40G QSFP ports. Check the Cisco Optics-to-Device Compatibility Matrix for your specific platform and software version.

Q: What is the difference between this and other QSFP-H40G-AOC lengths?
A: The AOC family differs by cable length. This SKU is the 30 m version with a green pull tab, and shorter or longer lengths use different part numbers.

Q: Can it be used with transceivers or breakout connections?
A: No. It is a fixed QSFP+ to QSFP+ assembly with the optics built into the cable, so it connects 40G QSFP ports directly and does not use separate transceivers.

Q: Is it suitable for hot-swapping?
A: Yes. The QSFP+ connectors are hot-swappable, so the cable can be inserted or removed while the device is powered.
