Cisco QSFP-H40G-AOC2M | 40G QSFP+ Active Optical Cable, 2m, Brown Pull Tab
SKU:QSFP-H40G-AOC2M
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The QSFP-H40G-AOC2M is a 2-metre 40 Gigabit Ethernet QSFP+ to QSFP+ active optical cable with the optics built into each end. It is designed for short-reach 40GbE links in data centres, high-performance computing, enterprise core and distribution layers, and service provider networks, such as top-of-rack to aggregation or switch-to-switch connections.
The cable uses 850 nm multimode optics and a fixed assembly, so no separate transceivers or fibre patch cords are needed. It has a 3.5 mm PVC jacket, a 60 mm bend radius at the QSFP end and a brown pull tab for easy identification. The host electrical interface is IEEE 802.3ba compliant, and the QSFP form factor and 2-wire I2C management interface follow SFF-8436 and the QSFP MSA. Operating temperature is 0 to 70 C and the assembly is RoHS 6 compliant.
It is hot-swappable and draws power from the host QSFP port, so no external power supply is required. It plugs into 40G QSFP/QSFP+ ports on Cisco platforms such as Nexus 3000, 5600 and 6000 and the 40GE QSFP ports on Catalyst 9800-H wireless controllers. Check the Cisco Optics-to-Device Compatibility Matrix for your exact platform and software release.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hot-swappable device that plugs into a 40 Gigabit Ethernet Cisco QSFP port
- Integrated optics and fixed cable, with no separate transceivers needed
- Interoperable with other IEEE-compliant 40GBASE interfaces where applicable
- Tested on Cisco QSFP 40G ports for performance, quality and reliability
- High-speed electrical interface compliant with IEEE 802.3ba
- QSFP form factor and 2-wire I2C interface compliant with SFF-8436 and the QSFP MSA
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Product type: Active Optical Cable (QSFP+ to QSFP+)
- Data rate: 40 Gigabit Ethernet (40GBASE)
- Length: 2 m
- Optics: 850 nm multimode, integrated
- Pull tab colour: Brown
- Cable diameter (QSFP end): 3.5 mm
- Jacket material: PVC
- Bend radius (QSFP end): 60 mm
- Face plate distance (QSFP end): 115 mm
- Host electrical interface: IEEE 802.3ba compliant
- Form factor and management interface: QSFP MSA, SFF-8436 (2-wire I2C)
- Bit-error rate: better than 1E-15
- Operating temperature: 0 to 70 C (32 to 158 F)
- Storage temperature: -40 to 85 C (-40 to 185 F)
- Power: drawn from the host QSFP port
- Compliance: RoHS 6
FAQs
Q: Does it need an external power supply?
A: No. The cable is powered from the host QSFP port and needs no external power supply.
Q: Which ports does it plug into?
A: It plugs into 40G QSFP/QSFP+ ports on Cisco platforms such as Nexus 3000, 5600 and 6000 and the 40GE QSFP ports on Catalyst 9800-H wireless controllers. Check the Cisco Optics-to-Device Compatibility Matrix for your exact platform and software release.
Q: Do I need separate transceivers or fibre patch cords?
A: No. The optics are integrated into both ends of the cable, so it connects two 40G QSFP ports directly.
Q: How does it differ from the other lengths in this range?
A: This SKU is the 2 m version with a brown pull tab. Other lengths use different part numbers.
Q: Is it hot-swappable?
A: Yes. It can be inserted into or removed from a 40G QSFP port while the switch is powered.
