Cisco QSFP-H40G-AOC25M | 40G QSFP+ Active Optical Cable, 850nm, 25m
SKU:QSFP-H40G-AOC25M
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The QSFP-H40G-AOC25M is a 25-metre 40 Gigabit Ethernet active optical cable with a QSFP connector at each end. It is built for short-reach links inside a rack and between adjacent racks in data centres, high-performance computing clusters, enterprise core and distribution layers, and service provider networks.
The optics are built into the cable assembly, so no separate transceivers or fibre patching are needed. It runs at a nominal 850 nm over multimode fibre, with a link bit error rate better than 1E-15 and an IEEE 802.3ba compliant electrical interface. Each end draws 1.5 W from the host QSFP port, and the cable has a 3.5 mm diameter with a 60 mm bend radius, which keeps dense racks tidy and helps airflow. The 25 m length separates it from the other lengths in the QSFP-H40G-AOC family.
It works with Cisco switches and routers that have 40G QSFP ports. No licence or subscription is required. Check the Cisco Optics-to-Device Compatibility Matrix for the exact platforms and software releases.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hot-swappable input/output device that plugs into a 40 Gigabit Ethernet Cisco QSFP port
- Optics are integrated into the cable, so no separate transceivers are needed
- Interoperable with other IEEE-compliant 40GBASE interfaces where applicable
- Certified and tested on Cisco QSFP 40G ports for performance, quality and reliability
- Much thinner and lighter than copper cables, which makes cabling easier
- Improves airflow in dense racks and has no EMI issues
- Available in 1, 2, 3, 5, 7, 10, 15, 20, 25 and 30 m lengths in the same family
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Type: QSFP to QSFP active optical cable (AOC)
- Speed: 40 Gigabit Ethernet (40GBASE)
- Length: 25 m
- Nominal wavelength: 850 nm (multimode)
- Power consumption: 1.5 W per end
- Pull tab colour: Green
- Jacket material: PVC
- Jacket colour: Orange
- Cable diameter (QSFP end): 3.5 mm
- Bend radius (QSFP end): 60 mm
- Face plate distance (QSFP end): 115 mm
- QSFP connector module dimensions (H x W x D): 13.5 x 18.4 x 72.4 mm
- QSFP connector module weight: 100 g or less (typical)
- Operating temperature: 0 to 70 C (32 to 158 F)
- Storage temperature: -40 to 85 C (-40 to 185 F)
- Link BER: better than 1E-15
- Electrical interface: IEEE 802.3ba compliant high-speed interface
- Management interface: 2-wire I2C, SFF-8436 and QSFP MSA compliant
- Standards: IEEE 802.3ba, QSFP+ MSA SFF-8436, RoHS 6
FAQs
Q: Does this cable need a licence or subscription?
A: No. It is a passive-managed hardware cable and needs no licence or subscription.
Q: How is it powered?
A: It is powered from the host QSFP port. The cable draws 1.5 W at each end, so no external power is required.
Q: What does it work with?
A: It is supported on Cisco switches and routers with 40G QSFP ports. Check the Cisco Optics-to-Device Compatibility Matrix for the exact platforms and software releases.
Q: How does it differ from the other QSFP-H40G-AOC cables?
A: The electrical and optical specifications are the same across the family. This SKU is the 25 m length, and the family also comes in 1, 2, 3, 5, 7, 10, 15, 20 and 30 m.
Q: Do I need separate transceivers or fibre patch leads?
A: No. The optical transceivers are built into each end of the cable assembly, so you simply plug it into the QSFP ports at each end.
