Cisco QSFP-H40G-AOC10M | 40G QSFP+ Active Optical Cable, 10m, Red Pull Tab
SKU:QSFP-H40G-AOC10M
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This is a 10 m fixed-length 40 Gigabit Ethernet active optical cable with a QSFP+ connector at each end. It links 40G QSFP ports on Cisco switches and routers over multimode fibre, and suits short-reach connections inside data centre racks and between adjacent racks, such as top-of-rack to aggregation or spine links.
The cable is an 850 nm multimode fibre assembly with an orange PVC jacket and a red pull tab, and the link bit-error rate is better than 1E-15. At 3.5 mm diameter at the QSFP end it is much thinner and lighter than copper DAC cable, which makes cabling easier, improves airflow in high-density racks and removes EMI concerns. It is powered from the host QSFP+ port, so no separate power supply is needed. It is one length in a range offered in 1, 2, 3, 5, 7, 10, 15, 20, 25 and 30 m.
It is supported on Cisco switches and routers with 40G QSFP/QSFP+ ports, including the Nexus 6004, Nexus 3164Q and Nexus 5624Q. Check the Cisco Optics-to-Device Compatibility Matrix for the exact platform and software release.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Much thinner and lighter than copper cables, which makes cabling easier
- Improves system airflow in high-density racks
- No EMI issues, which matters in high-density racks
- Suitable for very short distances within racks and across adjacent racks
- Link BER better than 1E-15, exceeding IEEE specifications
- Available in 1, 2, 3, 5, 7, 10, 15, 20, 25 and 30 m lengths across the range
- Supported on Cisco switches and routers with 40G QSFP/QSFP+ ports
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Product type: Active optical cable, 40GbE QSFP+ to QSFP+
- Cable length: 10 m
- Pull tab colour: Red
- Connector type: QSFP+ at both ends
- Cable type: Multimode fibre (MMF)
- Wavelength: 850 nm
- Bit-error rate (BER): better than 1E-15
- Jacket material: PVC
- Jacket colour: Orange
- Cable diameter (QSFP end): 3.5 mm
- Minimum bend radius (QSFP end): 60 mm
- Face plate distance (QSFP end): 115 mm
- QSFP connector module maximum outer dimensions (H x W x D): 13.5 x 18.4 x 72.4 mm
- QSFP connector module weight: typically 100 g or less
- Operating temperature: 0 to 70 C (32 to 158 F)
- Storage temperature: -40 to 85 C (-40 to 185 F)
- Power: Drawn from the host QSFP+ port, no separate supply needed
FAQs
Q: Does this cable need a separate power supply?
A: No. It is powered from the host QSFP+ port, so no separate power supply is needed.
Q: Which Cisco platforms support it?
A: It is supported on Cisco switches and routers with 40G QSFP/QSFP+ ports, including the Nexus 6004, Nexus 3164Q and Nexus 5624Q. Check the Cisco Optics-to-Device Compatibility Matrix for the exact platform and software release.
Q: How does it differ from the other lengths in this range?
A: This SKU is the 10 m version with a red pull tab. The same range is offered in 1, 2, 3, 5, 7, 15, 20, 25 and 30 m lengths.
Q: Why choose an active optical cable over copper DAC?
A: It is much thinner and lighter than copper DAC cable, improves airflow in high-density racks and is not affected by EMI.
Q: What is the operating temperature range?
A: The commercial operating range is 0 to 70 C (32 to 158 F).
