Cisco QSFP-H40G-ACU10M | 40G QSFP+ Active DAC Cable, 10m, Red Pull Tab
SKU:QSFP-H40G-ACU10M
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This 40GBASE-CR4 active direct-attach copper cable has a QSFP+ connector on each end and links two 40 Gigabit Ethernet QSFP ports over a 10 metre run. It is part of the Cisco 40GBASE QSFP portfolio and suits short-reach 40GbE links within and between racks in data centres, high-performance computing networks and enterprise core and distribution layers. Typical uses are top-of-rack to aggregation or leaf-to-spine connections where a copper run avoids the cost of optics.
The active electronics extend copper reach well beyond the passive QSFP-H40G-CU cables, which stop at 5 m. This 10 m assembly uses 26 AWG twinax in a black PVC jacket, with a red pull tab and a 9 mm cable diameter at the QSFP end. Each end draws about 1.5 W from the host port, and the cable needs no external power supply. It meets the IEEE 802.3ba standard and the QSFP+ MSA SFF-8436, with a bit-error rate better than 1E-15. No licence or subscription is required.
The cable is hot-swappable and works with Cisco switches and routers that have 40G QSFP+ ports. Check the Cisco Optics-to-Device Compatibility Matrix for the exact supported platforms and software versions.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hot-swappable device that plugs into a 40 Gigabit Ethernet QSFP port
- Active electronics extend copper reach beyond the 5 m limit of passive QSFP-H40G-CU cables
- High-speed electrical interface compliant with the IEEE 802.3ba standard
- QSFP form factor with a 2-wire I2C interface and low-speed electrical interfaces compliant with SFF-8436 and the QSFP MSA
- Certified and tested on Cisco QSFP 40G ports for performance, quality and reliability
- Interoperable with other IEEE-compliant 40GBASE interfaces where applicable
- Low power draw of about 1.5 W per end, with no external power supply needed
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Type: 40GBASE-CR4 QSFP+ to QSFP+ active copper direct-attach cable
- Cable length: 10 m
- Connector type: QSFP+ on both ends
- Power consumption: 1.5 W per end
- Cable gauge: 26 AWG
- Cable diameter (QSFP end): 9 mm
- Bend radius (QSFP end): 50 mm
- Face plate distance (QSFP end): 100 mm
- Jacket: PVC, black
- Pull tab colour: Red
- QSFP connector module maximum dimensions (H x W x D): 13.5 x 18.4 x 72.4 mm
- QSFP connector module weight: 100 g or less (typical)
- Operating temperature: 0 to 70 C (32 to 158 F)
- Storage temperature: -40 to 85 C (-40 to 185 F)
- Bit-error rate: better than 1E-15
- Standards: IEEE 802.3ba, QSFP+ MSA SFF-8436
- Safety: cable jacket UL E116441 compliant, ELV compliant
- Compliance: RoHS 6
FAQs
Q: Does this cable need a licence or subscription?
A: No. It is a plain direct-attach copper cable and requires no licence or subscription.
Q: How is it powered?
A: It has no external power supply. The active electronics draw about 1.5 W per end from the host QSFP port.
Q: How does it differ from the passive QSFP-H40G-CU cables?
A: This is an active cable, so its electronics extend copper reach to 10 m. The passive QSFP-H40G-CU cables stop at 5 m.
Q: Which devices does it work with?
A: It works with Cisco switches and routers that have 40G QSFP+ ports. Check the Cisco Optics-to-Device Compatibility Matrix for the exact supported platforms and software versions.
Q: Can I connect it to other 40GBASE interfaces?
A: Yes. It is interoperable with other IEEE-compliant 40GBASE interfaces where applicable, as it follows IEEE 802.3ba and the QSFP+ MSA SFF-8436.
