Cisco QSFP-4X10G-AOC5M | 40G QSFP+ to 4x 10G SFP+ AOC, 5m, 2m Breakout
SKU:QSFP-4X10G-AOC5M
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This 5 m active optical breakout cable connects one 40G QSFP+ port to four 10G SFP+ ports using an integrated 850 nm multimode assembly. It suits short-reach top-of-rack and aggregation links in data centres, high-performance computing and enterprise core or distribution networks, where one 40G switch port is split into four 10G server or switch links within a rack or to an adjacent rack.
The QSFP+ end carries a Gray pull tab and the cable splits into four SFP+ legs at a breakout point 2 m from the 40G end. Each end draws 1.5 W from the host port and the assembly is rated for 0 to 70 C operation. The QSFP+ electrical interface complies with IEEE 802.3ba, and management uses a 2-wire I2C interface compliant with SFF-8436 and the QSFP MSA. No licence or subscription is required.
It works with 40G QSFP ports and 10G SFP+ ports on Cisco switches. Cisco documentation lists support on platforms including Nexus 2300 FEX, Nexus 3164Q, Nexus 5624Q, Nexus 6004, Catalyst 2960-X/XR and the UCS VIC 1387. Check the support matrix for your platform and software version.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hot-swappable I/O device that plugs into a 40 Gigabit Ethernet QSFP port
- Splits one 40G port into four independent 10G SFP+ links
- Interoperable with other IEEE-compliant 40GBASE interfaces where applicable
- Tested on Cisco QSFP 40G ports for performance, quality and reliability
- High-speed electrical interface compliant with IEEE 802.3ba
- QSFP form factor with 2-wire I2C interface compliant with SFF-8436 and the QSFP MSA
- Thinner and lighter than copper cables, which makes cabling easier
- Supports efficient airflow and has no EMI issues in high-density racks
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Product type: QSFP+ to four SFP+ active optical breakout cable
- Cable assembly type: Active optical cable with integrated connectors
- Cable length: 5 m
- Wavelength: 850 nm (multimode fibre)
- Power consumption: 1.5 W at each end
- Pull tab colour: Gray
- Breakout location: 2 m from the 40G (QSFP+) end
- QSFP+ end cable diameter: 3.5 mm
- QSFP+ end bend radius: 60 mm
- QSFP+ end face plate distance: 100 mm
- SFP+ end cable diameter: 3 mm
- SFP+ end bend radius: 30 mm
- SFP+ end face plate distance: 80 mm
- Jacket material: PVC
- Jacket colour: Orange
- QSFP+ connector module maximum dimensions (H x W x D): 13.5 x 18.4 x 72.4 mm
- QSFP+ connector module weight: 100 g or less (typical)
- Operating temperature: 0 to 70 C (32 to 158 F)
- Storage temperature: -40 to 85 C (-40 to 185 F)
- Electrical interface: IEEE 802.3ba compliant high-speed electrical interface
- Management interface: 2-wire I2C and low-speed electrical interface compliant with SFF-8436 and QSFP MSA
FAQs
Q: Does this cable need a licence or subscription?
A: No. It is a passive-to-host cable assembly and needs no licence or subscription.
Q: How is it powered?
A: It is powered from the host QSFP+ and SFP+ ports. Power consumption is 1.5 W at each end.
Q: Where does the cable split into the four 10G legs?
A: The breakout location is 2 m from the 40G QSFP+ end, leaving the four SFP+ legs on the remaining length of the 5 m cable.
Q: Which platforms does it work with?
A: It connects a 40G QSFP port on a Cisco switch to four 10G SFP+ ports on a Cisco switch. Cisco lists support on Nexus 2300 FEX, Nexus 3164Q, Nexus 5624Q, Nexus 6004, Catalyst 2960-X/XR and UCS VIC 1387. Always check the support matrix for your platform and software version.
Q: What distance can this cable cover?
A: It is a fixed 5 m assembly with integrated connectors and 850 nm multimode optics, intended for very short links within a rack or between adjacent racks.
