Cisco

Cisco QSFP-40G-CSR-S | 40GBASE-CSR QSFP+ Transceiver, Duplex MMF, LC, 300m

SKU:QSFP-40G-CSR-S

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The QSFP-40G-CSR-S is a hot-swappable 40 Gigabit Ethernet QSFP+ optical transceiver built for short-reach links over duplex multimode fibre. It suits data centre, high-performance computing, enterprise core and distribution, and service provider 40G links, and is a practical choice when migrating from 10G to 40G on existing cabling.

Unlike many 40G short-reach optics that need MPO-12 parallel fibre, this 40GBASE-CSR module uses a duplex LC connector. It carries four 10G wavelengths (850, 880, 910 and 940 nm) over standard duplex multimode fibre, so existing 10G duplex MMF plant can be reused. Reach is 300 m on OM3, 400 m on OM4 and 440 m on OM5, depending on fibre quality. Power consumption is 3.5 W and the module is a Class 1 laser device with a 0 to 70 C operating range.

This module is certified and tested on Cisco QSFP 40G ports. Check the Cisco Transceiver Module Compatibility matrix for supported platforms and minimum software versions. FCoE is not supported.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swappable module that plugs into a 40 Gigabit Ethernet Cisco QSFP port
- Uses standard duplex LC multimode fibre, so existing 10G duplex MMF cabling can be reused for 40G
- Each of the four wavelengths runs at 10G over duplex MMF
- Supports OM5 fibre for extended reach up to 440 m, depending on fibre quality
- High-speed electrical interface compliant with IEEE 802.3ba
- QSFP form factor and 2-wire I2C interface compliant with SFF-8436 and the QSFP MSA
- Interoperable with other IEEE-compliant 40GBASE interfaces where applicable
- Certified and tested on Cisco QSFP 40G ports for performance, quality and reliability

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Product type: 40GBASE-CSR, duplex MMF
- Form factor: QSFP+ (QSFP MSA SFF-8436)
- Connector type: LC (duplex)
- Wavelength: Four lanes at 850, 880, 910 and 940 nm
- Cable type: Multimode fibre (MMF), 50.0 micron core
- Modal bandwidth at 850 nm: 2000 MHzkm (OM3), 4700 MHzkm (OM4), 4700 MHzkm (OM5)
- Cable distance: 300 m (OM3), 400 m (OM4), 440 m (OM5), depends on fibre quality
- Power consumption: 3.5 W
- Transmit power: +3 dBm max per lane, -7 dBm min per lane
- Receive power: +3 dBm max per lane, -9 dBm min per lane
- Link BER: 1E-12 guaranteed at 300/400/440 m on OM3/OM4/OM5
- Laser class: 1
- Pull tab colour: Orange
- Dimensions (H x W x D): 13.5 x 18.4 x 72.4 mm (maximum)
- Weight: 100 g or less (typical)
- Operating temperature: 0 to 70 C (32 to 158 F)
- Storage temperature: -40 to 85 C (-40 to 185 F)
- FCoE: Not supported
- Compliance: IEEE 802.3ba, QSFP+ MSA SFF-8436, SFP+ MSA SFF-8431/8461, RoHS 6

FAQs

Q: Does this module use MPO-12 or LC fibre connectors?
A: It uses a duplex LC connector, not MPO-12. It runs over a standard duplex multimode fibre pair, which lets you reuse existing 10G duplex MMF cabling.

Q: What reach can I expect on each fibre type?
A: Reach is 300 m on OM3, 400 m on OM4 and 440 m on OM5 multimode fibre. Actual distance depends on fibre quality.

Q: Which ports is it designed for?
A: It is certified for Cisco QSFP 40G ports. Check the Cisco Transceiver Module Compatibility matrix for supported platforms and minimum software versions.

Q: How much power does the module draw?
A: It consumes 3.5 W, powered from the host QSFP port, so no separate power supply is needed.

Q: Does it support FCoE?
A: No. FCoE is not supported on this module.

Q: How does it differ from other 40G short-reach QSFP+ modules?
A: This 40GBASE-CSR variant uses duplex LC multimode fibre with four wavelengths, rather than the parallel MPO-12 fibre used by 40GBASE-SR4 optics.
