Cisco

Cisco QSFP-200G-SR4-S | 200G QSFP56 SR4 Transceiver, MPO-12, 100m OM4

SKU:QSFP-200G-SR4-S

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The 200GBASE-SR4 QSFP56 transceiver carries 200 Gigabit Ethernet over short-reach multimode fibre at 850nm. It suits AI/ML data centre fabrics, server NIC connectivity and switch-to-switch links, and can also be used to migrate to higher speeds through 100G and 50G breakout.

The module runs four 50Gbps PAM4 lanes over parallel MMF and connects with an MPO-12 UPC interface. Reach is 70m over OM3 and 100m over OM4 or OM5, with a maximum supported insertion loss of 1.9 dB. It can be used as 2x100GBASE-SR2 or 4x50GBASE-SR breakout where the host platform supports it. Power consumption is 4.5 W, drawn from the host QSFP56 port, with an operating range of 0 to 70 C. No licence or subscription is required.

The QSFP56 form factor fits compatible ports on Cisco switches, routers and server NICs, as well as third-party host platforms and NICs. Breakout interoperates with SFP-50G-SR and 100GBASE-SR2 modules. Only patch cords with PC or UPC connectors are supported, and forward error correction is performed on the host platform.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Carries 200GE over four parallel MMF pairs at 850nm
- Supports 2x100GBASE-SR2 and 4x50GBASE-SR breakout modes on supported platforms
- Works in QSFP56 ports on Cisco switches, routers and NICs as well as third-party hosts and NICs
- Interoperates with Cisco and third-party modules that comply with the same standards
- Compliant with IEEE 802.3bm and 200GAUI-4 / CEI-56G-VSR-PAM4
- Forward error correction is performed on the host platform
- Low 4.5 W module power draw, powered entirely by the host port

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Standard: 200GBASE-SR4
- Form factor: QSFP56
- Nominal data rate: 200GE
- Electrical interface: 200GAUI-4 / OIF CEI-56G-VSR-PAM4
- Wavelength: 850 nm nominal
- Lanes: 4 x 50Gbps PAM4 over parallel MMF
- Cable type: MMF, 50 micron core
- Connector: MPO-12 MMF UPC
- Reach: 70m (OM3), 100m (OM4), 100m (OM5)
- Modal bandwidth: 2000 (OM3), 4700 (OM4), 4700 (OM5) MHzkm
- Breakout: 2x100GBASE-SR2 or 4x50GBASE-SR (SFP-50G-SR)
- Power consumption: 4.5 W
- Average transmit power per lane: -6.5 dBm min / 4 dBm max
- Average receive power per lane: -8.4 dBm min (informative) / 4 dBm max
- Maximum supported insertion loss: 1.9 dB
- Pre-FEC BER: 2.4x10-4 (FEC performed on host platform)
- Pull tab colour: Beige
- Dimensions with pull tab (H x W x D): 8.5 x 18.4 x 78.3/93.3 mm
- Weight: 100 g maximum
- Operating temperature: 0 to 70 C
- Storage temperature: -40 to 85 C
- Laser class: Class 1 (21CFR-1040, IEC60825-1)
- Standards: IEEE 802.3bm, IEEE 802.3-2022, QSFP56 MSA, OIF CEI-56G-VSR-PAM4, CMIS Rev 4.0
- Compliance: RoHS 6, FCC/ICES, CENELEC, VCCI, NEBS GR-1089, IEC/EN 60825-1 +A2

FAQs

Q: Does this transceiver need a licence or subscription?
A: No. It is powered and recognised through the host QSFP56 port and needs no licence or subscription.

Q: What fibre and connector does it use?
A: It uses 50 micron multimode fibre with an MPO-12 UPC connector. Only patch cords with PC or UPC connectors are supported.

Q: Can it be used for breakout links?
A: Yes, on supported platforms it can be used as 2x100GBASE-SR2 or 4x50GBASE-SR breakout. The breakout side interoperates with SFP-50G-SR and 100GBASE-SR2 modules, with up to 100m reach over OM4.

Q: What ports does it fit?
A: It fits QSFP56 ports on Cisco switches, routers and server NICs, and on third-party hosts and NICs. Check the Cisco Transceiver Modules Compatibility Matrix for per-platform support.

Q: What is the maximum reach?
A: Reach is 70m over OM3 and 100m over OM4 or OM5, within a maximum insertion loss of 1.9 dB.
