Cisco QSFP-100G-ZR4-S | 100G QSFP28 ZR4 Transceiver, 80km SMF, Duplex LC

SKU:QSFP-100G-ZR4-S

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This 100GBASE-ZR4 QSFP28 transceiver brings 80 km reach to a standard QSFP28 port, making it suited to extended-reach 100G links between distant sites over single-mode fibre. It offers a lower-cost route to long-haul 100G than coherent modules or external amplifier chassis, whether for a new build or an upgrade.

It runs at 100 Gbps in 100G mode only, with no 4x25G breakout, using four 25G NRZ lanes at 1295, 1300, 1304 and 1309 nm in the O-band. An integrated semiconductor optical amplifier overcomes attenuation, so no external amplifier is needed. The module connects with a Duplex LC interface over G.652 single-mode fibre, with a maximum engineered link loss of 29 dB and a minimum link attenuation of about 11 dB. Maximum power consumption is 5.5 W, it supports DOM, and it has a black pull tab.

The host port must generate and decode RS-FEC (528,514), as the module does not. It will not interoperate with transceivers that do not use RS-FEC, such as 100G-LR4, or with coherent optics. Check the Cisco Optics-to-Device compatibility matrix before ordering.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Delivers 80 km reach from a QSFP28 port, avoiding larger coherent modules or external chassis-based solutions
- Operates in the O-band, where fibre dispersion is minimal, using low-cost, low-power direct-detect technology
- Integrated SOA overcomes attenuation, so no external amplifier module is needed
- Digital optical monitoring provides optical-level information
- Multiplexing and demultiplexing of the four wavelengths is handled inside the module
- Designed for 100G operation with a Duplex LC single-mode interface

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Form factor: QSFP28
- Data rate: 100 Gbps (100G mode only, no 4x25G breakout)
- Reach: up to 80 km over SMF, depending on fibre and connector loss
- Fibre type: SMF G.652
- Optical connector: Duplex LC
- Nominal wavelengths: 1295, 1300, 1304, 1309 nm (four lanes)
- Modulation: NRZ, 4 x 25G optical and electrical lanes
- Transmit power per lane (max / min): +7 dBm / +2 dBm
- Receive power per lane (max / min): -4.5 dBm / -27 dBm
- Maximum engineered link loss: 29 dB
- Approximate minimum link attenuation: about 11 dB
- Power consumption: 5.5 W max
- Required host FEC: RS-FEC (528,514)
- Digital optical monitoring (DOM): Yes
- Operating temperature: 0 to 70 C
- Pull tab colour: Black
- Laser class: Class 1 (IEC 60825-1)
- Standards: SFF-8665 (QSFP28), SFF-8636, IEEE 802.3bm electrical interface

FAQs

Q: Does the host port need to support RS-FEC?
A: Yes. The host port must generate and decode RS-FEC (528,514), as the module does not. It cannot interoperate with transceivers that do not use RS-FEC, such as 100G-LR4.

Q: Will it link with 100G coherent optics?
A: No. This module uses direct-detect technology and does not interoperate with 100G coherent transceivers.

Q: Is there a minimum link distance?
A: Yes. The minimum link attenuation is about 11 dB, which is roughly a 20 km minimum reach. Shorter links may need attenuation added to protect the receiver.

Q: Can it be used in 4x25G breakout mode?
A: No. It operates in 100G mode only, with no 4x25G breakout.

Q: What cooling does it need?
A: Power draw reaches 5.5 W at maximum operating temperature. The host platform must keep the module at or below 70 C, which often needs front-to-back airflow.
