Cisco QSFP-100G-LR4-I | 100G QSFP28 LR4 Transceiver, 10km SMF, I-Temp
SKU:QSFP-100G-LR4-I
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This 100GBASE-LR4 QSFP28 transceiver carries 100 Gigabit Ethernet over a duplex LC pair of G.652 single-mode fibre, with a reach of up to 10 km. It is built for data centre, high-performance computing, enterprise core and distribution, and service provider 100G links where an industrial temperature range is required.
The module multiplexes four wavelengths (1295, 1300, 1304 and 1309 nm) internally and complies with IEEE 100GBASE-LR4 without using FEC. It operates from -40 to 85 C, which is what separates this industrial-temperature version from the standard QSFP-100G-LR4-S. Transmit power is +4.5 dBm max and -4.3 dBm min per lane, receive power is +4.5 dBm max and -10.6 dBm min per lane, and power consumption is 4.0 W maximum, drawn from the host QSFP28 port.
It is supported on Cisco switches and routers with QSFP28 100G ports, so check the Cisco 100 Gigabit Ethernet Transceiver Modules Compatibility Matrix for your platform and software release. It shares the IEEE 100GBASE-LR4 optical interface with QSFP-100G-LR4-S and CPAK LR4 modules.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hot-swappable module that plugs into a 100 Gigabit Ethernet Cisco QSFP28 port
- Industrial temperature support from -40 to 85 C
- Complies with IEEE 100GBASE-LR4 without using FEC
- High-speed electrical interface compliant with IEEE 802.3bm
- Four-wavelength multiplexing and demultiplexing handled within the module
- Interoperable with other IEEE-compliant 100GBASE-LR4 interfaces
- Certified and tested on Cisco QSFP-100G ports for performance and reliability
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Form factor: QSFP28
- Standard: IEEE 100GBASE-LR4
- Connector: LC (duplex)
- Fibre type: G.652 single-mode (SMF)
- Reach: up to 10 km
- Lane wavelengths: 1295, 1300, 1304, 1309 nm
- Operating temperature: -40 to 85 C (-40 to 185 F)
- Storage temperature: -40 to 85 C (-40 to 185 F)
- Power consumption: 4.0 W (max)
- Transmit power per lane: +4.5 dBm (max) / -4.3 dBm (min)
- Receive power per lane: +4.5 dBm (max) / -10.6 dBm (min)
- Electrical interface: IEEE 802.3bm compliant
- FEC: not used
- Pull tab colour: Blue
- Dimensions (H x W x D): 13.5 x 18.4 x 72.4 mm
FAQs
Q: How does this differ from QSFP-100G-LR4-S?
A: Both use the same IEEE 100GBASE-LR4 optical interface. This I-Temp version is rated for -40 to 85 C operation, suited to harsher environments.
Q: Does it need a licence or subscription?
A: No. It is a passive optical module powered from the host QSFP28 port and requires no separate licence.
Q: How much power does it draw?
A: Maximum power consumption is 4.0 W per module, supplied by the host QSFP28 port.
Q: What fibre does it use and how far will it reach?
A: It uses duplex LC connectors over G.652 single-mode fibre, with a reach of up to 10 km.
Q: What will it work with?
A: It works with Cisco switches and routers that have QSFP28 100G ports, and it interoperates with other IEEE 100GBASE-LR4 interfaces such as QSFP-100G-LR4-S and CPAK LR4. Check the Cisco compatibility matrix for your platform and software.
