Cisco QSFP-100G-ER4L-S | 100G QSFP28 ER4-Lite Transceiver, 40km SMF, Duplex LC
SKU:QSFP-100G-ER4L-S
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This is a 100G QSFP28 ER4-Lite optical transceiver from Cisco's 100GBASE QSFP-100G module range. It runs 100 Gigabit Ethernet over four CWDM4 wavelengths on a duplex LC single-mode fibre pair, and is aimed at long-reach links such as data centre interconnect, metro and campus backbone, and service provider aggregation.
Reach is 40 km with host FEC enabled, or 30 km without FEC. The four lanes sit at 1295, 1300, 1304 and 1309 nm over G.652 single-mode fibre, with multiplexing and demultiplexing handled inside the module. Maximum power consumption is 4.5 W, drawn from the host QSFP port, and the commercial operating range is 0 to 70 C. No licence or subscription is required.
The module is backward compatible with Cisco CPAK ER4-Lite (up to 25 km) and IEEE 100GBASE-ER4 optics such as the Cisco CFP 100G ER4 (up to 30 km). It also interoperates with Cisco QSFP100 and CPAK 100GBASE-LR4 modules up to 10 km. It is supported on Cisco switches and routers with 100G QSFP28 ports.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hot-swappable module that plugs into a 100 Gigabit Ethernet Cisco QSFP port
- Four-wavelength CWDM4 design on a single duplex LC fibre pair
- High-speed electrical interface compliant with IEEE 802.3bm
- Backward compatible with Cisco CPAK ER4-Lite and IEEE 100GBASE-ER4 transceivers
- Interoperates with Cisco QSFP100 and CPAK 100GBASE-LR4 modules up to 10 km
- Internal multiplexing and demultiplexing of the four wavelengths
- Tested on Cisco QSFP-100G ports for performance and reliability
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Form factor: QSFP28 (QSFP100)
- Standard: 100GBASE ER4-Lite
- Connector: duplex LC
- Fibre type: single-mode G.652
- Reach: 40 km with host FEC, 30 km without host FEC
- Wavelengths: 1295, 1300, 1304 and 1309 nm (four lanes)
- Transmit power per lane: +6.5 dBm max, -2.5 dBm min
- Receive power per lane: -3.5 dBm max, -20.5 dBm min with FEC; -17 dBm min without FEC
- Minimum channel insertion loss: 6.4 dB
- Power consumption: 4.5 W
- Operating temperature: 0 to 70 C (32 to 158 F)
- Storage temperature: -40 to 85 C (-40 to 185 F)
- Dimensions (H x W x D): 13.5 x 18.4 x 72.4 mm
- Weight: typically 100 g or less
- Pull tab colour: Red
- Electrical interface: IEEE 802.3bm compliant
- Compliance: SFF-8665, SFF-8636, IEEE 802.3-2022, IEEE 802.3ba, IEEE 802.3bm, RoHS 6
- Laser safety: Class 1 (IEC 60825-1)
FAQs
Q: Does this transceiver need a licence or subscription?
A: No. No licence or subscription is required. It is a passive plug-in optic that works as soon as the host port supports it.
Q: Do I need FEC enabled to reach 40 km?
A: Yes. The full 40 km reach needs FEC on the host platform. Without host FEC the reach is 30 km.
Q: How much power does it draw?
A: Maximum power consumption is 4.5 W, drawn from the host QSFP port. It has no separate power supply.
Q: What can it link to at the far end?
A: It interoperates with Cisco CPAK ER4-Lite, the Cisco CFP 100G ER4 (up to 30 km), and QSFP100 or CPAK 100GBASE-LR4 modules up to 10 km.
Q: Which Cisco platforms support it?
A: It is supported on Cisco switches and routers with 100G QSFP28 ports. Check the Cisco 100 Gigabit Ethernet Transceiver Modules Compatibility Matrix for exact platform and software support.
