Cisco QSFP-100G-4W40-I | 100G QSFP28 Transceiver, SMF, 40km, Duplex LC, I-Temp
SKU:QSFP-100G-4W40-I
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This 100GBASE 4W40 transceiver is a hot-swappable QSFP28 optic from the Cisco QSFP-100G module range. It carries 100 Gigabit Ethernet over a duplex single-mode fibre pair with LC connectors, making it suited to long-reach data centre interconnect and metro links of 30 to 40km, including deployments that need an industrial temperature rating.
The module uses four lanes at 1295, 1300, 1304 and 1309 nm, with multiplexing and demultiplexing handled inside the module. Reach is 40km with host FEC and 30km without. Power consumption is 4.5 W, and it operates across the industrial range of -40 to 85 C. Digital optical monitoring is built in, and the module has a red pull tab.
It is supported on Cisco switches and routers with 100 Gigabit Ethernet QSFP ports, and full 40km reach requires FEC on the host platform. It interoperates with Cisco CPAK ER4-Lite, IEEE 100GBASE-ER4 optics such as CFP 100G ER4 up to 30km, and Cisco QSFP100 and CPAK 100GBASE-LR4 modules up to 10km. No licence or subscription is required.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hot-swappable module that plugs into a 100 Gigabit Ethernet Cisco QSFP port
- Carries 100G Ethernet over four wavelengths on a duplex single-mode fibre pair
- Multiplexing and demultiplexing of the four wavelengths handled inside the module
- Digital optical monitoring (DOM) for real-time link diagnostics
- Industrial temperature rating of -40 to 85 C
- Interoperable with other IEEE-compliant 100GBASE interfaces where applicable
- Certified and tested on Cisco QSFP-100G ports
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Form factor: 100GBASE QSFP28
- Connector: LC (duplex)
- Fibre type: Single-mode, G.652
- Wavelengths: 1295, 1300, 1304, 1309 nm (four lanes)
- Maximum distance: 40km with host FEC, 30km without host FEC
- Power consumption: 4.5 W
- Transmit power per lane: +6.5 dBm max, -2.5 dBm min
- Receive power per lane: -3.5 dBm max; -20.5 dBm min with FEC, -16 dBm min without FEC
- Operating temperature: -40 to 85 C (-40 to 185 F)
- Storage temperature: -40 to 85 C (-40 to 185 F)
- Dimensions (H x W x D): 13.5 x 18.4 x 72.4 mm
- Weight: typically 100 g or less
- Host electrical interface: IEEE 802.3bm compliant
- Pull tab colour: Red
- Digital optical monitoring: Yes (DOM)
FAQs
Q: Does this transceiver need a licence or subscription?
A: No. It is a passive optical module and needs no licence or subscription. It draws up to 4.5 W from the host QSFP28 port.
Q: Do I need FEC enabled to reach 40km?
A: Yes. The full 40km reach requires FEC on the host platform. Without host FEC the supported distance is 30km.
Q: What fibre and connector does it use?
A: It uses G.652 single-mode fibre with a duplex LC connector.
Q: Which optics can it link to?
A: It is backward compatible with Cisco CPAK ER4-Lite up to 25km and IEEE 100GBASE-ER4 such as CFP 100G ER4 up to 30km. It also interoperates with Cisco QSFP100 and CPAK 100GBASE-LR4 modules up to 10km.
Q: Which Cisco platforms support it?
A: It is supported on Cisco switches and routers with 100 Gigabit Ethernet QSFP ports. Check the Cisco 100 Gigabit Ethernet Transceiver Modules Compatibility Matrix for the exact platforms.
Q: What is the difference between this and a standard-temperature 4W40 module?
A: This I-Temp version is rated for -40 to 85 C operation, suiting outdoor cabinets, industrial sites and other environments beyond the standard commercial range.
