Cisco

Cisco QDD-4X100G-FR-S | 400G QSFP-DD Transceiver, 4x100G FR1, MPO-12 APC, 2km

SKU:QDD-4X100G-FR-S

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This 400G QSFP-DD optical transceiver is built for data centre and service provider links that need to break one 400G port out into four 100G connections. It runs four 100GBASE-FR1 lanes at 1310 nm over parallel single-mode fibre and is suited to 400G-to-4x100G migrations of up to 2 km.

The module uses an MPO-12 APC connector and supports a link length of up to 2 km on G.652 single-mode fibre, with a maximum supported insertion loss of 4 dB. Average transmit power is -3.1 to 4 dBm per lane. The high-speed electrical interface is 400GAUI-8/CEI-56G-VSR-PAM4, and maximum power consumption is 12 W, drawn from the host port with no external power required. APC-polished MPO-12 patch cords are required, not PC or UPC.

In breakout mode it connects to 100G QSFP28 interfaces, including QSFP-100G-DR-S (500 m), QSFP-100G-FR-S (2 km) and QSFP-100G-LR-S (2 km), as well as QDD-4X100G-LR-S. It is intended for Cisco switches and routers with QSFP-DD ports, and exact platform support should be checked in the Cisco Transceiver Modules Compatibility Matrix.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swappable module that plugs into QSFP-DD 400G Ethernet ports
- Breakout mode lets one QSFP-DD port operate as four 100GE ports on supported platforms
- Interoperable with other IEEE-compliant interfaces where applicable
- Tested and certified on Cisco QSFP-DD 400G ports
- Compliant with IEEE 802.3 electrical and optical interfaces and QSFP-DD MSA CMIS Rev 4.1
- QSFP-DD port is backward compatible with QSFP+, QSFP28 and QSFP56 modules
- Forward error correction is performed on the host platform

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Form factor: 400G QSFP-DD
- Data rate: 4x 100GE (4 x 100GBASE-FR1 breakout)
- Wavelength: 1310 nm
- Fibre type: Parallel single-mode fibre (SMF G.652)
- Link length: 2 km
- Optical connector: MPO-12 SMF APC
- Number of fibres: 12 (4 pairs used)
- High-speed electrical interface: 400GAUI-8/CEI-56G-VSR-PAM4
- Maximum power consumption: 12 W
- Average transmit power per lane: -3.1 to 4 dBm
- Average receive power per lane: -7.1 to 4 dBm
- Maximum supported insertion loss: 4 dB
- Pre-FEC BER: 2.4x10-4
- Dimensions with pull tab (H x W x D): 8.5 x 18.4 x 78.3/93.3 mm
- Weight: 100 g maximum
- Operating temperature: 0 to 75 C
- Storage temperature: -40 to 85 C
- Standards: IEEE 802.3cu 100GBASE-FR1, QSFP-DD MSA CMIS Rev 4.1, OIF 56G PAM4, 100G Lambda MSA

FAQs

Q: Which 100G optics can this breakout connect to?
A: It interoperates with QSFP-100G-DR-S (up to 500 m), QSFP-100G-FR-S (2 km) and QSFP-100G-LR-S or QDD-4X100G-LR-S (2 km) at the far end.

Q: What type of patch cord does it need?
A: It uses an MPO-12 connector and requires APC-polished MPO-12 single-mode patch cords. PC or UPC polish is not suitable.

Q: Does it need a licence or external power?
A: No licence is required. It draws a maximum of 12 W from the host QSFP-DD port and needs no external power.

Q: Which platforms is it designed for?
A: It is designed for Cisco switches and routers with QSFP-DD 400G ports. Check the Cisco Transceiver Modules Compatibility Matrix for exact platform and breakout support.

Q: What is the maximum reach?
A: Up to 2 km over parallel G.652 single-mode fibre, with a maximum supported insertion loss of 4 dB.
