Cisco QDD-400G-ZRP-S | 400G QSFP-DD ZR+ Coherent Transceiver, C-band Tunable
SKU:QDD-400G-ZRP-S
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The Cisco 400G Digital Coherent Optics QSFP-DD transceiver follows the OpenZR+ MSA and tunes across the full C-band. It suits regional to long-haul data centre interconnect over amplified DWDM systems, reaching well beyond the 120 km of 400ZR. It also fits IP-over-DWDM and Routed Optical Networking designs, where the router's pluggable port takes the place of a separate transponder.
The module carries 100G, 200G, 300G or 400G per wavelength using 16-QAM, 8-QAM or QPSK modulation with oFEC. Client modes cover 400GE, 4x100GE, 3x100GE, 2x100GE and 1x100GE, with a roundtrip latency of 4.7 microseconds in 400GE mode. Optical performance includes 42 dB OOB and OIB OSNR, a 13 dBm maximum receive power and a default chromatic dispersion tolerance of +/-13,000 ps/nm at 400G, configurable up to +/-52,000 ps/nm. Two transmit filter shaping options are supported, with or without TX shaping.
Host platforms are listed in the Cisco ZR/ZR+ support matrix and include ASR 9000 line cards, NCS 5500 and Cisco 8000 platforms. Cisco also publishes configuration guides for Nexus 9000 hosts. Check the Cisco Transceiver Module Compatibility Matrix for exact port and software support.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- OpenZR+ MSA compliant for multivendor interoperability
- oFEC from OpenROADM gives higher coding gain and reach well beyond the 120 km of 400ZR
- Multirate Ethernet client support from 100GE to 400GE with adjustable 100G/200G/300G/400G line rates
- Two Tx filter shaping configurations, plus extra modulation and baud-rate options beyond the OpenZR+ MSA
- Higher dispersion tolerance than 400ZR
- The same port can run from 400G down to 100G by swapping the pluggable, keeping backward compatibility with previous-generation routers
- IP-over-DWDM using the router's pluggable port, with the same port density as grey line cards
- 7-nm DSP and silicon photonics integrate a full coherent WDM interface in a QSFP-DD form factor
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Form factor: QSFP-DD, digital coherent optics (DCO)
- Standard: OpenZR+ MSA
- Frequency range: C-band, 196.1 to 191.3 THz, fully tunable
- Line rate: 100G / 200G / 300G / 400G per wavelength
- Modulation: 16-QAM, 8-QAM, QPSK
- FEC: oFEC (cFEC also supported)
- Client modes: 400GE, 4x100GE, 3x100GE, 2x100GE, 1x100GE
- Symbol rate: about 60.14 GBaud (400G 16-QAM, 300G 8-QAM, 200G QPSK)
- OOB OSNR / OIB OSNR: 42 dB / 42 dB
- Max transmit power, 400G 16-QAM: -8.0 dBm typical without TX shaping, -11.0 dBm typical with TX shaping
- Rx OSNR sensitivity, 400G 16-QAM: 23.7 dB without TX shaping, 23.1 dB with TX shaping
- Rx power sensitivity, 400G 16-QAM: -20 dBm without TX shaping, -21 dBm with TX shaping
- Max Rx power: 13 dBm
- Chromatic dispersion robustness, 400G 16-QAM: +/-13,000 ps/nm default, up to +/-52,000 ps/nm configurable
- DGD robustness: 60 ps (400G, 300G, 200G modes), 80 ps (100G QPSK)
- Roundtrip latency: 4.7 microsec (400GE), 5.2 microsec (4x100GE)
- MTBF: 442,477 hrs
FAQs
Q: How does this differ from a 400ZR module?
A: This module follows OpenZR+ and uses oFEC, which gives longer reach than the 120 km of 400ZR. It also supports multirate line speeds from 100G to 400G and has higher dispersion tolerance.
Q: Which line rates and client modes does it support?
A: It runs 100G, 200G, 300G or 400G per wavelength. Client modes are 400GE, 4x100GE, 3x100GE, 2x100GE and 1x100GE.
Q: Which host platforms support it?
A: Supported hosts are listed in the Cisco ZR/ZR+ support matrix. They include ASR 9000 line cards, NCS 5500 and Cisco 8000 platforms, with Nexus 9000 configuration guides also published. Check the Cisco Transceiver Module Compatibility Matrix for exact port and software support.
Q: What wavelength range can it tune across?
A: It tunes across the full C-band, 196.1 to 191.3 THz, so a single part number covers the DWDM channel plan.
Q: Is it intended for short data centre links?
A: No. It is designed for regional to long-haul data centre interconnect over amplified DWDM systems, and for IP-over-DWDM designs.
