Cisco

Cisco QDD-400G-ZR-S | 400G-ZR QSFP-DD Coherent Transceiver, C-band, LC

SKU:QDD-400G-ZR-S

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco 400G Digital Coherent Optics QSFP-DD module in its 400G-ZR (OIF 400ZR) variant is a hot-pluggable coherent transceiver for edge data centre interconnect. It lets routers and switches with QSFP-DD ports carry IP-over-DWDM traffic directly, without separate transponders, over duplex LC single-mode fibre.

The module is full C-band tunable and carries one 400G wavelength using 16-QAM modulation with C-FEC at a symbol rate of 59.84 GBd. It supports both 400GE and 4x100GE host interfaces. Point-to-point reach is up to 120 km with mux/demux and amplification. Receive sensitivity is -12 dBm optimal, with a maximum receive power of 13 dBm. Roundtrip latency is 7.9 microseconds for 400GE and 8.2 microseconds for 4x100GE. The operating case temperature range is 15 to +75 C.

Cisco documents this optic in its 400G Digital Coherent Optics configuration guides for IOS XR on NCS 5500, ASR 9000 and Cisco 8000, and for Nexus 9000 NX-OS. As an OIF 400ZR module it is built for multivendor interoperability. It is not interchangeable at the line-side signal level with the OpenZR+ variant, QDD-400G-ZRP-S.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Integrated coherent pluggable: 400G digital coherent WDM interface in a QSFP-DD form factor, built on 7-nm DSP and silicon photonics
- OIF 400ZR compliant for multivendor interoperability
- Supports both 400GE and 4x100GE host interfaces
- Full C-band tunability
- Suited to edge data centre interconnect, point-to-point up to 120 km with mux/demux and amplification
- Enables IP-over-DWDM on router line cards without separate transponders
- Tested across Cisco and multivendor platforms

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Form factor: QSFP-DD
- Variant: 400G-ZR (OIF 400ZR), MSA compliant
- Technology: digital coherent optics (DCO)
- Tunability: full C-band
- Modulation: 16-QAM (400G)
- FEC: C-FEC
- Symbol rate: 59.84 GBd (+/-20 ppm)
- Host interface: 400GE and 4x100GE
- Connector: duplex LC, single-mode fibre
- Reach: up to 120 km (amplified point-to-point)
- Max transmit power: -8.5 dBm typical, -10 dBm worst case
- OOB OSNR: 30 dB
- OIB OSNR: 34 dB
- Rx OSNR sensitivity: 26 dB
- Rx sensitivity (optimal): -12 dBm
- Rx sensitivity (extended range): -15 dBm
- Max Rx power: 13 dBm
- CD robustness: +/-2400 ps/nm
- DGD robustness: 33 ps
- Operating case temperature: 15 to +75 C
- MTBF: 442,477 hours
- Roundtrip latency: 7.9 microseconds (400GE), 8.2 microseconds (4x100GE)

FAQs

Q: Does this transceiver need a licence or subscription?
A: No licence or subscription is specified for this transceiver.

Q: Which Cisco platforms is it documented for?
A: Cisco documents it in its 400G Digital Coherent Optics guides for IOS XR on NCS 5500, ASR 9000 and Cisco 8000, and for Nexus 9000 NX-OS. Confirm exact platform and software support in the Cisco Optics-to-Device Compatibility Matrix.

Q: Is it interchangeable with the ZR+ module QDD-400G-ZRP-S?
A: No. QDD-400G-ZRP-S uses OpenZR+ with O-FEC, while this module is OIF 400ZR with C-FEC, so they are not interchangeable at the line-side signal level.

Q: Will it interoperate with other vendors' 400ZR optics?
A: Yes. It is OIF 400ZR compliant and designed for multivendor interoperability with other OIF 400ZR modules.

Q: How does it differ from other 400G coherent variants?
A: This SKU is the 400G-ZR variant, running 16-QAM at 400G only with C-FEC, and is full C-band tunable.
