Cisco QDD-400G-SR8-S | 400G QSFP-DD Transceiver, 400GBASE-SR8, MPO-16, 100m
SKU:QDD-400G-SR8-S
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The QDD-400G-SR8-S is a hot-swappable 400G QSFP-DD optical transceiver for short-reach data centre links over multimode fibre. It suits operators who need 400GE connectivity between switches and routers within a row or room, or high-density breakout to lower-speed server and switch ports.
It runs 400GBASE-SR8, using eight 50G PAM4 lanes at a nominal 850nm wavelength over 50 micron multimode fibre with an MPO-16 APC connector. Reach is 70m on OM3 and 100m on OM4. Maximum power consumption is 12 W, drawn from the host port with no separate power supply, and the operating temperature range is 0 to 75 C. No licence or subscription is required. The module can also break out to 2x 200G-SR4 or 8x 50G-SR links.
It fits Cisco QSFP-DD 400G ports and requires MPO-16 APC patch cords, as PC/UPC connectors are not supported. Breakout partners are SFP56-50G-SR for 8x 50G and QSFP-200G-SR4-S for 2x 200G. The optical interface is also interoperable with 400GBASE-SR4 and 800GBASE-SR8 in breakout mode.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hot-swappable, plugs into Cisco 400G QSFP-DD ports
- Certified and tested on Cisco QSFP-DD 400G ports
- Breakout to 8x SFP56-50G-SR modules or 2x QSFP-200G-SR4-S modules
- Interoperable with IEEE-compliant 400GBASE interfaces where applicable
- Compliant with IEEE 802.3, QSFP-DD MSA CMIS Rev 4.1, OIF 56G PAM4 and 100G Lambda MSA
- QSFP-DD ports are backward compatible with QSFP+, QSFP28 and QSFP56 modules
- FEC is performed on the host platform
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Form factor: QSFP-DD (400G)
- Standard: 400GBASE-SR8, 8 x 50G PAM4 lanes
- Nominal wavelength: 850 nm (range 840-860 nm)
- Fibre type: MMF, 50 micron core
- Optical connector: MPO-16 APC
- Reach: 70m on OM3, 100m on OM4
- Breakout reach (2x 200GE / 8x 50G): 70m OM3, 100m OM4, 100m OM5
- Modal bandwidth: 2000 MHzkm (OM3), 4700 MHzkm (OM4 and OM5)
- Nominal datarate: 425 Gbps
- High-speed electrical interface: 400GAUI-8 / CEI-56G-VSR-PAM4
- Average transmit power per lane: -6.5 dBm min, 4 dBm max
- Average receive power per lane: -8.4 dBm min, 4 dBm max
- Maximum supported insertion loss: 1.9 dB
- Pre-FEC BER: 2.4x10-4
- Max power consumption: 12 W
- Operating temperature: 0 to 75 C
- Storage temperature: -40 to 85 C
- Dimensions with pull tab (H x W x D): 8.5 x 18.4 x 78.3/93.3 mm
- Weight: 100 g maximum
- Pull tab colour: Tan
- Laser class: Class 1
- Compliance: IEEE 802.3, QSFP-DD MSA CMIS Rev 4.1, RoHS 6
FAQs
Q: Does this transceiver need a licence or subscription?
A: No. No licence or subscription is required. The module is powered from the host QSFP-DD port.
Q: What fibre and connector does it use?
A: It uses 50 micron multimode fibre with an MPO-16 APC connector. MPO-16 APC patch cords are required, and PC/UPC connectors are not supported.
Q: What reach can I expect?
A: Reach is 70m on OM3 and 100m on OM4 for 400GE. Breakout links reach 70m on OM3 and 100m on OM4 or OM5.
Q: Can it break out to lower speeds?
A: Yes. It can break out to 2x 200G-SR4 using QSFP-200G-SR4-S modules, or 8x 50G-SR using SFP56-50G-SR modules.
Q: How much power does it draw?
A: Maximum power consumption is 12 W, drawn from the host QSFP-DD port. No separate power supply is needed.
