Cisco

Cisco QDD-400G-LR8-S | 400G QSFP-DD Transceiver, LR8, 10km SMF, Duplex LC

SKU:QDD-400G-LR8-S

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco QDD-400G-LR8-S is a hot-swappable 400GBASE-LR8 QSFP-DD optical transceiver from the Cisco 400G QSFP-DD module range. It carries 400G Ethernet over duplex single-mode fibre with an LC connector, making it suited to 400G links in data centres, high-performance computing, enterprise core and distribution layers, and service provider networks.

The module uses eight 50G PAM4 lanes on LAN-WDM wavelengths around 1310 nm (1273, 1277, 1282, 1286, 1295, 1300, 1304 and 1309 nm) to reach up to 10 km over G.652 single-mode fibre. Average transmit power is -2.8 to 5.3 dBm per lane, average receive power is -9.1 to 5.3 dBm per lane, and the maximum supported insertion loss is 6.3 dB. Maximum power consumption is 13 W, drawn from the host port, and the module operates from 0 to 75 C. No licence or subscription is required.

It is supported on Cisco switches and routers with QSFP-DD 400G ports and interoperates with other IEEE-compliant 400GBASE-LR8 optics. Check the Cisco Transceiver Modules Compatibility Matrix for the exact platforms.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swappable, plugs into Cisco 400G QSFP-DD ports
- Interoperable with other IEEE-compliant 400GBASE interfaces
- Certified and tested on Cisco QSFP-DD 400G ports
- Compliant with IEEE 802.3 and the QSFP-DD MSA (CMIS)
- Eight 50G PAM4 lanes on LAN-WDM wavelengths for 400G over a single duplex fibre pair
- QSFP-DD ports are backward compatible with QSFP+, QSFP28 and QSFP56 modules
- Laser Class 1

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Form factor: QSFP-DD
- Standard: 400GBASE-LR8
- Reach: 10 km over duplex single-mode fibre (G.652)
- Connector: Duplex LC SMF PC/UPC
- Wavelengths: 1273, 1277, 1282, 1286, 1295, 1300, 1304, 1309 nm (LAN-WDM, 8 lanes)
- Average transmit power per lane: -2.8 dBm min / 5.3 dBm max
- Average receive power per lane: -9.1 dBm min / 5.3 dBm max
- Maximum supported insertion loss: 6.3 dB
- Pre-FEC bit error ratio: 2.4x10-4
- Electrical interface: 400GAUI-8 / CEI-56G-VSR-PAM4
- Maximum power consumption: 13 W
- Dimensions with pull tab (H x W x D): 8.5 x 18.4 x 78.3/93.3 mm
- Weight: 100 g maximum
- Operating temperature: 0 to 75 C
- Storage temperature: -40 to 85 C
- Laser class: Class 1 (21CFR-1040 LN#50, IEC60825-1)
- Standards: IEEE 802.3bs 400GAUI-8, IEEE 802.3cu CL140, QSFP-DD MSA Rev 4.1, CMIS

FAQs

Q: Does this transceiver need a licence or subscription?
A: No. The QDD-400G-LR8-S does not require any licence or subscription.

Q: How much power does it draw?
A: Maximum power consumption is 13 W, supplied by the host QSFP-DD port. It needs no separate power supply.

Q: What fibre and connector does it use?
A: It uses duplex single-mode fibre (G.652) with a duplex LC PC/UPC connector, for links up to 10 km.

Q: Will it link to a 400GBASE-LR4 module at the far end?
A: No. LR8 uses eight wavelengths and LR4 uses four, so the two do not interoperate. Both ends of a link need 400GBASE-LR8 optics, including IEEE-compliant LR8 modules from other vendors.

Q: Which platforms support it?
A: It is supported on Cisco switches and routers with QSFP-DD 400G ports. Check the Cisco Transceiver Modules Compatibility Matrix for the exact platforms and software releases.
