Cisco

Cisco QDD-400G-LR4-S | 400G QSFP-DD Transceiver, 400G-LR4, 10km Duplex LC

SKU:QDD-400G-LR4-S

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This 400G QSFP-DD transceiver carries 400 Gigabit Ethernet over duplex single-mode fibre with an LC connector. It is suited to data centre, high-performance computing, enterprise core and distribution, and service provider 400GbE links up to 10 km.

The module is a 400GBASE-LR4 optic that uses four CWDM wavelengths at 1270, 1290, 1310 and 1330 nm, with multiplexing and demultiplexing handled inside the module. It is fully compliant with IEEE 802.3cu 400GBASE-LR4-6 and extends the reach from 6 km to 10 km over G.652 single-mode fibre. The host interface is 400GAUI-8, forward error correction is performed on the host platform, and maximum power consumption is 12 W. Operating temperature is 0 to 75 C.

It is supported on Cisco switches and routers with 400G QSFP-DD ports and interoperates with IEEE 400GBASE-LR4-6 modules, and with 400GBASE-FR4 modules at 2 km. Check the Cisco Transceiver Modules Compatibility Matrix for exact platforms and software versions. No licence or subscription is required.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swappable, plugs into a 400G Ethernet Cisco QSFP-DD port
- Four CWDM wavelengths multiplexed and demultiplexed inside the module
- Complies with QSFP-DD MSA CMIS Rev 4.1, OIF 56G PAM4, IEEE 802.3 and 100G Lambda MSA
- Interoperates with 400GBASE-LR4 peers (6 km at 6.3 dB)
- Interoperates with 400GBASE-FR4 peers (2 km at 4 dB)
- QSFP-DD ports are backward compatible with QSFP+, QSFP28 and QSFP56 modules

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Form factor: QSFP-DD (QSFP double density)
- Standard: 400GBASE-LR4, compliant with IEEE 802.3cu 400GBASE-LR4-6 and 100G Lambda MSA 400G-LR4
- Reach: 10 km over SMF G.652
- Connector: Duplex LC SMF PC/UPC
- Wavelengths: 1270, 1290, 1310, 1330 nm (CWDM grid)
- Nominal data rate: 425 Gbps
- Electrical interface: 400GAUI-8 / CEI-56G-VSR-PAM4
- Average transmit power per lane: -2.7 dBm min to 5.1 dBm max
- Average receive power per lane: -9.0 dBm min to 5.1 dBm max
- Maximum supported insertion loss: 6.3 dB
- Pre-FEC BER: 2.4x10-4 (FEC performed on host platform)
- Maximum power consumption: 12 W
- Dimensions with pull tab (H x W x D): 8.5 x 18.4 x 78.3/93.3 mm
- Maximum weight: 100 g
- Operating temperature: 0 to 75 C
- Storage temperature: -40 to 85 C

FAQs

Q: Does this transceiver need a licence or subscription?
A: No. It is a passive optical module and requires no licence or subscription.

Q: What fibre does it need?
A: It uses duplex single-mode fibre (G.652) with LC connectors and reaches up to 10 km.

Q: Which devices does it work with?
A: It is supported on Cisco switches and routers with 400G QSFP-DD ports. Check the Cisco Transceiver Modules Compatibility Matrix for exact platforms and software versions.

Q: Will it link to a 400GBASE-LR4-6 module at the other end?
A: Yes. It is fully compliant with IEEE 802.3cu 400GBASE-LR4-6, so it interoperates with those modules, with a 6 km reach at 6.3 dB loss.

Q: Can it link to a 400GBASE-FR4 optic?
A: Yes, it interoperates with 400GBASE-FR4 modules at up to 2 km.

Q: How much power does it draw?
A: Maximum power consumption is 12 W, drawn from the host QSFP-DD port.
