Cisco

Cisco QDD-400G-FR4-S | 400G QSFP-DD Transceiver, 400G-FR4, 2km SMF, LC

SKU:QDD-400G-FR4-S

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This 400G QSFP-DD optical transceiver carries 400 Gigabit Ethernet over a duplex single-mode fibre pair with LC connectors, reaching up to 2 km. It is built for data centre, high-performance computing, enterprise core and distribution, and service provider networks where 400G links of up to 2 km are needed over standard G.652 fibre.

It complies with IEEE 802.3cu 400GBASE-FR4 and the 100G Lambda MSA. Four CWDM wavelengths (1270, 1290, 1310 and 1330 nm) are multiplexed and demultiplexed inside the module, so only a single duplex fibre pair is required. The host interface is 400GAUI-8 / CEI-56G-VSR-PAM4, with forward error correction performed on the host platform. Maximum power consumption is 12 W, and the module operates from 0 to 75 C.

The module is supported in Cisco QSFP-DD 400G ports on Cisco switches and routers, and the QSFP-DD cage is backward compatible with QSFP+, QSFP28 and QSFP56 modules. It interoperates at 2 km with another QDD-400G-FR4-S and with QDD-2X400G-FR4. It also interoperates with QDD-400G-LR4-S at the 2 km reach.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swappable input/output device for Cisco 400G QSFP-DD ports
- Certified and tested on Cisco QSFP-DD 400G ports
- Interoperable with other IEEE-compliant 400GBASE interfaces
- Compliant with QSFP-DD MSA CMIS Rev 4.1, OIF 56G PAM4, IEEE 802.3 and 100G Lambda MSA
- Four CWDM wavelengths multiplexed and demultiplexed inside the module
- Compliant with RoHS 6, Laser Class 1 (IEC 60825-1) and NEBS standards

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Standard: IEEE 802.3cu 400GBASE-FR4, 100G Lambda MSA 400G-FR4
- Form factor: QSFP-DD
- Optical connector: Duplex LC SMF PC/UPC
- Link length: 2 km
- Fibre type: SMF G.652
- Wavelengths: 1270, 1290, 1310, 1330 nm
- Nominal data rate: 425 Gbps
- Electrical interface: 400GAUI-8 / CEI-56G-VSR-PAM4
- Average transmit power per lane: -3.2 dBm min / 3.5 dBm max
- Average receive power per lane: -7.3 dBm min / 3.5 dBm max
- Maximum supported insertion loss: 4 dB
- Pre-FEC BER: 2.4x10-4
- FEC: performed on the host platform
- Maximum power consumption: 12 W
- Operating temperature: 0 to 75 C
- Storage temperature: -40 to 85 C
- Dimensions with pull tab (H x W x D): 8.5 x 18.4 x 78.3/93.3 mm
- Weight (max): 100 g
- Laser class: 1
- Cable colour code: Green

FAQs

Q: Does this transceiver need a software licence?
A: No. The QDD-400G-FR4-S does not require a software licence.

Q: What type of fibre does it use?
A: It uses a duplex single-mode fibre pair (G.652) terminated with LC PC/UPC connectors, for links up to 2 km.

Q: How much power does it draw?
A: Maximum power consumption is 12 W per module, drawn from the host QSFP-DD port. Forward error correction is performed on the host platform.

Q: Which ports is it compatible with?
A: It is supported in Cisco QSFP-DD 400G ports on Cisco switches and routers. Check the Cisco Transceiver Modules Compatibility Matrix for the specific platform.

Q: Which modules can it link to at the other end?
A: At 2 km with 4 dB maximum insertion loss it interoperates with another QDD-400G-FR4-S, QDD-2X400G-FR4 and QDD-400G-LR4-S. It also interoperates with other IEEE-compliant 400GBASE-FR4 interfaces.
