Cisco QDD-400G-FR4-G | 400G QSFP-DD Transceiver, 400GBASE-FR4, 2km, Duplex LC

SKU:QDD-400G-FR4-G

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The QDD-400G-FR4-G is a 400G QSFP-DD optical transceiver built for the 400GBASE-FR4 standard. It carries a 400GE signal over duplex single-mode fibre to a reach of 2 km, making it suited to 400G leaf-spine and aggregation uplinks in data centre and other high-density networks.

Inside the module, four CWDM wavelengths (1270, 1290, 1310 and 1330 nm) are multiplexed and demultiplexed, so the link needs only a single duplex LC pair rather than parallel optics. The high-speed electrical interface is 400GAUI-8 (CEI-56G-VSR-PAM4). Maximum power consumption is 12 W, drawn from the host QSFP-DD port, and the module operates from 0 to 75 C. Forward error correction is performed on the host platform, not in the module.

It is intended for Cisco switches and routers with QSFP-DD ports. Check the Cisco Transceiver Modules Compatibility Matrix for platform and software support. At the 2 km FR4 reach, it interoperates with QDD-400G-FR4-S and QDD-2X400G-FR4.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Compliant with IEEE 802.3cu for 400GBASE-FR4 and the 100G Lambda MSA
- Four CWDM wavelengths multiplexed and demultiplexed inside the module
- Duplex LC connector reduces fibre count compared with parallel optics
- 400GAUI-8 host electrical interface for QSFP-DD ports
- Host-side forward error correction, performed by the switch or router
- Draws power from the host port with no separate power supply

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Form factor: QSFP-DD
- Standard: 400GBASE-FR4 (IEEE 802.3cu / 100G Lambda MSA)
- Reach: 2 km over G.652 single-mode fibre
- Wavelengths: 1270, 1290, 1310, 1330 nm (CWDM4)
- Connector: Duplex LC (SMF PC/UPC)
- Nominal data rate: 425 Gbps
- High-speed electrical interface: 400GAUI-8 / CEI-56G-VSR-PAM4
- Max power consumption: 12 W
- Average transmit power per lane: -3.2 to 3.5 dBm
- Average receive power per lane: -7.3 to 3.5 dBm
- Maximum supported insertion loss: 4 dB
- Pre-FEC BER: 2.4x10-4
- Module dimensions with pull tab (H x W x D): 8.5 x 18.4 x 78.3/93.3 mm
- Module weight (max): 100 g
- Operating temperature: 0 to 75 C
- Storage temperature: -40 to 85 C
- Pull-tab colour: Green

FAQs

Q: What fibre and reach does this transceiver support?
A: It runs over duplex G.652 single-mode fibre with Duplex LC connectors, up to 2 km. The maximum supported insertion loss is 4 dB.

Q: Does it need a separate power supply?
A: No. It draws a maximum of 12 W from the host QSFP-DD port.

Q: Which platforms is it compatible with?
A: It is designed for Cisco switches and routers with QSFP-DD ports. Check the Cisco Transceiver Modules Compatibility Matrix for platform and software support.

Q: Does the module perform forward error correction?
A: No. FEC is performed on the host platform, so the host must support 400GBASE-FR4 FEC.

Q: Which other optics will it link with at 2 km?
A: At the 2 km FR4 reach it interoperates with QDD-400G-FR4-S and QDD-2X400G-FR4.
