Cisco QDD-2X100-LR4-S | QSFP-DD 2x100G LR4 Breakout Transceiver, Dual CS, 10km

SKU:QDD-2X100-LR4-S

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This Cisco QSFP-DD breakout transceiver presents two independent 100GBASE-LR4 links over single-mode fibre, with a reach of up to 10 km through a dual duplex CS connector. It suits data centre, high-performance computing, enterprise core and distribution, and service provider networks that are moving to 400G platforms while keeping links to existing 100GBASE-LR4 equipment.

The module carries 2 x 100GE with a 2x 100G CAUI-4 host electrical interface and uses wavelengths of 1295, 1300, 1304 and 1309 nm. Link budget is 6.3 dB maximum insertion loss over SMF G.652, with average transmit power of -4.3 to 4.5 dBm per lane. Maximum power consumption is 8 W, drawn from the host QSFP-DD port, and no licence or subscription is required. FEC is performed on the host platform.

It works in Cisco switches and routers with 400G QSFP-DD ports, in breakout mode on specific platforms. Over 10 km it interoperates with QSFP-100G-LR4-S, CPAK-100G-LR4, CPAK-100GE-LR4 and CFP-100G-LR4 optics. Only patch cords with PC or UPC connectors are supported.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swappable module for Cisco QSFP-DD 400G ports
- Supports link lengths up to 10 km over single-mode fibre using a dual duplex CS connector
- Compliant with IEEE 802.3 100GBASE-LR4 requirements
- Breakout operation to two 100GBASE-LR4 transceivers, improving port efficiency towards legacy 100G optical interfaces
- QSFP-DD port is backward compatible with QSFP+, QSFP28 and QSFP56 modules
- Certified and tested by Cisco on QSFP-DD 400G ports
- Compliant with QSFP-DD MSA, CMIS, Laser Class 1, NEBS and RoHS 6

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Form factor: QSFP-DD
- Nominal data rate: 2 x 100GE (2 x 100GBASE-LR4 breakout)
- High-speed electrical interface: 2x 100G CAUI-4
- Link length: 10 km
- Cable type: SMF G.652
- Optical connector: Dual Duplex CS, SMF PC/UPC
- Nominal wavelengths: 1295, 1300, 1304, 1309 nm
- Average transmit power per lane: -4.3 to 4.5 dBm
- Average receive power per lane (max): 4.5 dBm
- Average receive power per lane (min, informative): -10.6 dBm
- Maximum supported insertion loss: 6.3 dB
- Pre-FEC BER: 10^-12 (no FEC)
- Maximum power consumption: 8 W
- Operating temperature: 0 to 70 C
- Storage temperature: -40 to 85 C
- Module dimensions with pull tab (H x W x D): 8.5 x 18.4 x 78.3/93.3 mm
- Module weight (max): 100 g
- Pull tab colour: Blue
- Laser class: 1
- Standards: IEEE 802.3 100GBASE-LR4, QSFP-DD MSA CMIS, RoHS 6

FAQs

Q: Does this transceiver need a licence or subscription?
A: No. No licence or subscription is required to use this module.

Q: How much power does it draw?
A: Maximum power consumption is 8 W, drawn from the host QSFP-DD port.

Q: Which optics can it link to at 10 km?
A: Over 10 km of SMF with 6.3 dB insertion loss it interoperates with QSFP-100G-LR4-S, CPAK-100G-LR4, CPAK-100GE-LR4 and CFP-100G-LR4.

Q: Which Cisco ports does it work in?
A: It is supported on Cisco switches and routers with 400G QSFP-DD ports, in breakout mode on specific platforms. Check the Cisco Transceiver Modules Compatibility Matrix for your platform.

Q: What fibre patch cords should be used?
A: Use single-mode fibre patch cords with PC or UPC connectors and a dual duplex CS interface. Other connector types are not supported.
