Cisco QDD-2X100-CWDM4-S | QSFP-DD 2x100G CWDM4 Transceiver, Dual Duplex CS, 2km SMF
SKU:QDD-2X100-CWDM4-S
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This QSFP-DD optical transceiver from the Cisco 400G QSFP-DD cable and transceiver module family operates as two independent 100G-CWDM4 links over single-mode fibre. It lets a single 400G-class QSFP-DD port connect to two separate 100G CWDM4 interfaces, reaching up to 2 km. It suits data centre teams migrating from 100G to 400G platforms port by port, and anyone needing higher 100G port density.
The module follows the 100G-CWDM4 MSA with a nominal data rate of 2x 100GE and a 2x 100G CAUI-4 host electrical interface. Each 100G link uses four CWDM wavelengths at 1271, 1291, 1311 and 1331 nm, with multiplexing and demultiplexing handled inside the module. Optical connection is through a dual duplex CS connector on SMF G.652 fibre, with a maximum supported insertion loss of 5 dB. FEC is performed on the host platform. Maximum power consumption is 7 W and the operating temperature range is 0 to 70 C.
It interoperates with QSFP-100G-CWDM4-S (2 km, 5 dB budget) and QSFP-100G-SM-SR (2 km, 4.2 dB budget) at the far end. It is supported on Cisco switches and routers with QSFP-DD ports, and requires PC/UPC duplex patch cords with CS connectors, which can be fanned out to duplex LC.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Breakout module: one QSFP-DD port provides two 100G-CWDM4 links for higher 100G port density
- Eases migration from 100G to 400G platforms on a port-by-port basis
- Interoperates with modules that comply with the same 100G-CWDM4 standards
- Multiplexing and demultiplexing of four CWDM wavelengths at 25 Gb/s each is handled within the module
- FEC is performed on the host platform
- Dual duplex CS connector fans out to duplex LC
- Colour-coded green for 2 km SMF reach
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Form factor: QSFP-DD
- Standard: 100G-CWDM4 MSA (2 x 100G)
- Nominal data rate: 2x 100GE
- Host electrical interface: 2x 100G CAUI-4
- Maximum reach: 2 km
- Fibre type: SMF G.652
- Wavelengths: 1271, 1291, 1311, 1331 nm (nominal 1270, 1290, 1310, 1330 nm)
- Average transmit power per lane: -6.5 dBm min / 2.5 dBm max
- Average receive power per lane: -11.5 dBm min / 2.5 dBm max
- Maximum supported insertion loss: 5 dB
- Pre-FEC BER: 5x10^-5 (FEC performed on host platform)
- Optical connector: Dual Duplex CS, SMF PC/UPC
- Max power consumption: 7 W
- Dimensions with pull tab (H x W x D): 8.5 x 18.4 x 78.3/93.3 mm
- Weight (max): 100 g
- Operating temperature: 0 to 70 C
- Storage temperature: -40 to 85 C
- Laser safety: Class 1 (21CFR-1040, IEC60825-1)
FAQs
Q: Does this transceiver need a licence or subscription?
A: No. The module itself does not require a licence or subscription.
Q: What can it connect to at the far end?
A: It interoperates with QSFP-100G-CWDM4-S (2 km, 5 dB budget) and QSFP-100G-SM-SR (2 km, 4.2 dB budget). Each of the two 100G links connects to a separate 100G CWDM4 interface.
Q: What fibre and patch cords does it need?
A: It runs over single-mode fibre (SMF G.652) and needs PC/UPC duplex patch cords with CS connectors. APC cords are not suitable. Each CS port can be fanned out to duplex LC.
Q: How much power does it draw?
A: Maximum power consumption is 7 W per module, drawn from the host QSFP-DD port.
Q: Which platforms is it used in?
A: It is used in Cisco switches and routers with QSFP-DD ports. Check the Cisco Transceiver Modules Compatibility Matrix for your exact platform and software release.
