• Cisco P-LPWA-900 LoRaWAN PIM 900 MHz gateway module
1 1

Cisco

Cisco P-LPWA-900 | LoRaWAN Pluggable Module, 900 MHz, 8-Channel, AU915

P-LPWA-900

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The P-LPWA-900 is a pluggable LoRaWAN gateway radio module for the Cisco Catalyst IR1101 Rugged Series Router. It adds LoRaWAN gateway capability to the IR1101, which suits IoT deployments such as utilities and remote sensing across the Americas and Asia-Pacific.

This is the 900 MHz variant with eight LoRa channels, covering the US915, AU915 and AS923 regional profiles in the 902-928 MHz ISM band. The module has one SMA(f) LoRa RF connector and one SMA(f) GNSS connector, plus LoRa Power and LoRa Status LEDs. It is managed through the CLI or the IOS XE Web UI and requires IOS XE 17.10.1 or later. Australia defaults to the AU915 channel plan, with AS923 also available. The companion P-LPWA-800 covers EU868, IND865 and RU864.

It installs in the IR1101 Base module or in the IRM-1100-SP and IRM-1100-SPMI expansion modules, with one LoRaWAN module supported per router. Supported antennas include ANT-LPWA-SMA-D, ANT-LPWA-DB-O-N-5 and ANT-WPAN-OD-OUT-N, with the GPS-ACT-ANTM-SMA GNSS antenna.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Eight-channel LoRaWAN gateway radio in a pluggable form factor
- Covers the US915, AU915 and AS923 regional profiles
- Managed via CLI or IOS XE Web UI
- GPS/GNSS-based channel-plan verification: the radio will not turn on if the GPS fix is outside a supported country
- Australia defaults to the AU915 channel plan, with AS923 also available
- Power and Status LEDs show module state and LoRa interface operation

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Model: P-LPWA-900
- LoRa channels: 8
- Frequency band: 900 MHz (902-928 MHz ISM)
- Regional RF profiles: US915, AU915, AS923
- Supported LoRa antenna frequency range: 863-928 MHz
- Connectors: 1 x LoRa RF SMA(f), 1 x GNSS SMA(f)
- Indicators: LoRa Power LED, LoRa Status LED
- Dimensions (H x W x D): 6.35 x 2.16 x 8.38 cm (2.50 x 0.85 x 3.30 in)
- Weight: 181.4 g (0.4 lb)
- Management: CLI or Cisco IOS XE Web UI
- Minimum software: IOS XE 17.10.1
- Host platform: Cisco Catalyst IR1101
- Interface numbering on IR1101: LORAWAN 0/1/0 (base) or LORAWAN 0/3/0 (expansion)
- Maximum modules per IR1101: 1
- Online insertion and removal (OIR): not supported

FAQs

Q: Which router does the P-LPWA-900 work with?
A: It works with the Cisco Catalyst IR1101 Rugged Series Router, installed in the Base module or the IRM-1100-SP or IRM-1100-SPMI expansion modules. It requires IOS XE 17.10.1 or later, and only one LoRaWAN module is supported per IR1101.

Q: What is the difference between the P-LPWA-900 and the P-LPWA-800?
A: The P-LPWA-900 covers the 900 MHz profiles US915, AU915 and AS923. The P-LPWA-800 covers EU868, IND865 and RU864.

Q: Is a GPS signal needed to use the module?
A: Yes. The radio will not turn on if the GPS fix is outside a supported country, and a GPS lock is mandatory for the Common Packet Forwarder application. The GPS-ACT-ANTM-SMA GNSS antenna is the supported option.

Q: Which antennas can be used with the LoRa connector?
A: Supported LoRa antennas are ANT-LPWA-SMA-D (1.0 dBi), ANT-LPWA-DB-O-N-5 (5.6 dBi) and ANT-WPAN-OD-OUT-N (1.5 dBi). Lightning arrestors CGR-LA-NM-NF and CGR-LA-NF-NF are also supported.

Q: Can the module be hot-swapped?
A: No. Physical online insertion and removal is not supported, so the module should not be inserted or removed while the router is running.
