• Cisco N9K-C93180YC-FX24 switch with 24x SFP28 and 6x QSFP28 ports
1 1

Cisco

Cisco N9K-C93180YC-FX24 | Nexus 9300-FX 24-Port 1/10/25G SFP28 Switch, 6x 100G QSFP28

N9K-C93180YC-FX24

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Cisco Nexus 93180YC-FX-24 is a high-performance 1RU data center switch engineered for leaf-spine deployments in enterprise and cloud-scale environments. Delivering 24 flexible SFP28 ports supporting 1G/10G/25G speeds and 6 QSFP28 uplink ports with 40G/100G connectivity, this switch provides 3.6 Tbps of switching capacity with sub-microsecond latency. Built on Cisco NX-OS, it supports advanced features including VXLAN, EVPN, MACsec encryption, and ACI fabric integration for modern software-defined data center architectures.

Features

Layer 2 and Layer 3 switching with wire-rate performance
- VXLAN and EVPN support for overlay network virtualization
- MACsec hardware-based encryption for line-rate security
- Virtual PortChannel (vPC) for device-level redundancy
- Cisco Tetration Analytics support for deep telemetry
- Cisco ACI fabric integration for policy-based automation
- Flexible port breakout: 4x10G and 4x25G from QSFP28 ports
- Unified Fibre Channel and Ethernet ports (8/16/32 Gb FC support)
- Advanced routing protocols: BGP, OSPF, EIGRP, IS-IS, PIM
- Quality of Service (QoS): 8 egress queues, WRED, ECN
- 40 MB shared system buffer for burst absorption
- Python and Ansible automation with open APIs
- Power On Auto Provisioning (POAP) for zero-touch deployment
- IEEE 802.1X authentication and port security
- Comprehensive SNMP, NETCONF, RESTCONF management
- Hot-swappable dual redundant power supplies and fans

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

24x 1/10/25 Gigabit Ethernet SFP28 ports
- 6x 40/100 Gigabit Ethernet QSFP28 uplink ports
- Switching capacity: 3.6 Tbps
- Forwarding rate: 2.6 Bpps (billion packets per second)
- Latency: <1 microsecond (cut-through)
- MAC address table: 512K entries
- Memory: 16 GB RAM, 64 GB SSD
- VLANs supported: 4096
- VRF instances: Up to 16,000 (model dependent)
- ACL entries: 4000 ingress, 2000 egress
- Form factor: 1RU rack-mountable
- Dual redundant power supplies (sold separately)
- Management: Console, USB, out-of-band Ethernet
- Operating temperature: 0°C to 40°C (32°F to 104°F)
- Weight: 7.9 kg (17.4 lb) without power supplies
- Software: Cisco NX-OS (requires subscription license)

FAQs

Q: What license is required for the N9K-C93180YC-FX-24?
A: This switch requires a Cisco NX-OS or ACI subscription license (Essentials or Advantage tier) for full functionality. The -24 designation indicates this is a 24-port model that can be upgraded to 48 ports with an optional license (N9K-FX-24P-UPG=).

Q: Does this switch support both NX-OS standalone mode and ACI fabric mode?
A: Yes, the Nexus 93180YC-FX-24 supports both Cisco NX-OS standalone mode for traditional data center deployments and ACI fabric mode when integrated with Cisco Application Policy Infrastructure Controllers (APICs) for software-defined networking.

Q: What is the maximum switching capacity and what deployment scenarios is it suited for?
A: With 3.6 Tbps switching capacity and 2.6 Bpps forwarding rate, this switch is ideal for high-density leaf-spine architectures, top-of-rack deployments, and aggregation layers in enterprise data centers requiring low-latency 25G server connectivity and 100G spine uplinks.

Q: Does the N9K-C93180YC-FX-24 support breakout cables on the QSFP28 ports?
A: Yes, the 6 QSFP28 uplink ports support flexible breakout options including 4x10G and 4x25G configurations, enabling seamless migration from legacy 10G environments to high-density 25G connectivity.

Q: What advanced features are supported for modern data center architectures?
A: The switch supports VXLAN overlay networks, EVPN for multi-tenancy, MACsec hardware encryption, Virtual PortChannel (vPC) for redundancy, Cisco Tetration Analytics integration, and comprehensive Layer 2 and Layer 3 routing protocols including BGP, OSPF, EIGRP, and IS-IS.
