• Cisco Catalyst 9300 N9K-C93108TC-FX24 48-port Ethernet switch
1 1

Cisco

Cisco N9K-C93108TC-FX24 | Nexus 9300-FX 24-Port 10GBASE-T Switch, 6x 40/100G QSFP28

N9K-C93108TC-FX24

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Cisco N9K-C93108TC-FX24 Nexus 93108TC-FX-24 is a compact 1RU data center switch designed for top-of-rack and leaf-spine deployments in enterprise and cloud environments. With 24 active 10GBASE-T ports supporting 100M/1G/10G speeds and six 40/100G QSFP28 uplinks, it delivers 2.16 Tbps switching capacity and over 1.2 Bpps forwarding performance. The switch features MACsec encryption on 10G and higher ports, VXLAN EVPN support, and operates on Cisco NX-OS with Essentials or Advanced licensing tiers.

Features

Cisco Cloud Scale ASIC architecture for wire-rate performance
- VXLAN EVPN fabric support for Layer 2 and Layer 3 overlay networks
- Cisco ACI-ready for automated, policy-driven data center management
- MACsec hardware encryption on 10G and higher ports for secure east-west traffic
- Virtual PortChannel (vPC) for redundant and load-balanced uplinks
- Comprehensive Layer 2 features: VLANs (4096), STP, RSTP, MSTP, LACP
- Advanced Layer 3 routing: BGP, OSPF, EIGRP, ECMP (64 paths), VRF (16,000 instances)
- Quality of Service (QoS) with 8 queues per port
- Access Control Lists (ACLs) with hardware-based ingress and egress filtering
- 40 MB shared packet buffer for handling bursty east-west traffic
- IGMP snooping and multicast routing (PIM-SM, SSM)
- Hot-swappable dual power supplies with N+1 redundancy
- Hot-swappable fans with selectable airflow direction (port-to-PSU or PSU-to-port)
- Dual out-of-band management: RJ45 and SFP+ management ports
- Power-on Auto Provisioning (POAP) for zero-touch deployment
- Latency: sub-microsecond for predictable performance in high-frequency trading and real-time applications

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

24 x 10GBASE-T RJ45 downlink ports (active, from 48 total physical ports)
- Port speeds: 100 Mbps / 1 Gbps / 10 Gbps auto-negotiation
- 6 x 40/100 Gigabit QSFP28 uplink ports
- Switching capacity: 2.16 Tbps
- Forwarding rate: 1.2 Bpps (billion packets per second)
- System buffer: 40 MB shared buffer
- MAC address table: 512K entries
- Memory: 24 GB RAM
- Layer 3 routing and switching
- MACsec support on 10G and higher ports (IEEE 802.1ae)
- Management: Dual out-of-band (RJ45 + SFP+), CLI, NX-OS, ACI-ready
- Routing protocols: BGP, OSPF, EIGRP, RIP, HSRP, PIM-SM, MSDP, MPLS, ECMP
- Power: Dual hot-swappable power supplies (N+1 redundancy)
- Fans: 4 x hot-swappable, selectable airflow
- Form factor: 1RU rack-mountable
- Weight: Approximately 17.4 lb (7.9 kg)

FAQs

Q: What is the difference between the N9K-C93108TC-FX and N9K-C93108TC-FX24?
A: The N9K-C93108TC-FX24 is a port-licensed variant with 24 active 10GBASE-T ports out of 48 total physical ports, whereas the N9K-C93108TC-FX has all 48 ports active. Both share the same hardware platform and uplink configuration (6 x 40/100G QSFP28).

Q: Does this switch support Power over Ethernet (PoE)?
A: No, the N9K-C93108TC-FX24 does not support PoE or PoE+. It is designed for data center applications where power is supplied directly to connected servers and appliances.

Q: What licensing options are available for this model?
A: The N9K-C93108TC-FX24 supports NX-OS Essentials and NX-OS Advantage licensing tiers. Essentials includes base Layer 2 and Layer 3 features, while Advantage adds advanced routing, VXLAN, and security capabilities. The switch can also run Cisco ACI for policy-based automation.

Q: Can I use existing Cat6 or Cat6A cabling with this switch?
A: Yes, the 10GBASE-T ports are designed to work with standard Cat6 or Cat6A copper cabling, supporting 100M, 1G, and 10G speeds. This allows for easy brownfield migrations without requiring new fiber infrastructure.

Q: What uplink transceiver types are supported in the QSFP28 ports?
A: The QSFP28 uplink ports support 40G and 100G transceivers, including 40GBASE-SR4, 100GBASE-SR4, 100GBASE-LR4, and compatible DAC/AOC cables. The ports provide flexible migration options for spine connectivity in leaf-spine architectures.
