Cisco N9K-C93108TC-EX24 | Nexus 9300-EX 24-Port 10GBASE-T Switch, 6x 40/100G QSFP28

N9K-C93108TC-EX24

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Cisco Nexus 93108TC-EX-24 is a 1RU data center switch designed for top-of-rack deployments in enterprise and cloud environments. With 24 licensed 10GBASE-T ports configurable at 100Mbps, 1Gbps, or 10Gbps speeds and 6 QSFP28 uplinks supporting 40/100Gbps, it delivers 2.16 Tbps switching capacity and flexible migration options. Powered by NX-OS with support for VXLAN, EVPN, and comprehensive Layer 2/3 features, this switch is ideal for scalable data center leaf-spine architectures.

Features

Cloud Scale ASIC with flexible forwarding and advanced telemetry
- VXLAN EVPN support for overlay networking
- Virtual PortChannel (vPC) for dual-homed server redundancy
- In-Service Software Upgrade (ISSU) for zero-downtime maintenance
- Comprehensive Layer 2 features: VLANs, Spanning Tree, LACP
- Layer 3 IP routing: OSPF, BGP, EIGRP, static routing (with license)
- IP multicast: PIM, IGMP snooping (with license)
- Advanced security: MACsec support on uplinks (with license), CoPP, RBAC, AAA
- Quality of Service: 8 hardware queues, DSCP/CoS marking, strict priority, WRED
- Network visibility: sFlow, NetFlow, SPAN, ERSPAN
- Programmability: Python scripting, NX-API, YANG models, NETCONF/RESTCONF
- Hot-swappable dual power supplies and N+1 fan redundancy
- Cisco Tetration Analytics telemetry at line rate
- Flexible airflow options for hot-aisle/cold-aisle deployment
- Upgrade path to 48 active ports with license purchase

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

24 x 10GBASE-T RJ-45 downlink ports (licensed to use any 24 of 48 total ports)
- 6 x 40/100G QSFP28 uplink ports
- Downlink speeds: 100Mbps, 1Gbps, or 10Gbps configurable
- Uplink speeds: 40Gbps or 100Gbps
- Switching capacity: 2.16 Tbps
- Forwarding rate: 1.6 billion packets per second
- MAC address table: up to 256,000 entries
- Routing table: up to 896,000 LPM routes (EX series)
- Memory: 16 GB RAM
- Storage: 64 GB SSD
- CPU: Dual-core 2.5 GHz x86
- System buffer: 40 MB
- Management: CLI, NX-API, NETCONF, RESTCONF, gRPC
- Power supply: Dual redundant hot-swappable (sold separately)
- Fans: 4 hot-swappable N+1 redundant
- Airflow: Back-to-front or front-to-back
- Dimensions: 1.7 in H x 17.3 in W x 22.5 in D (1RU)
- Weight: 17.7 lbs (8.0 kg)
- Operating temperature: 32°F to 104°F (0°C to 40°C)
- Certifications: UL, CE, FCC Class A, RoHS compliant

FAQs

Q: What is the difference between the EX-24 and the standard EX model?
A: The N9K-C93108TC-EX-24 has 48 physical ports but is licensed to use only 24 downlink ports. This provides a cost-effective entry point with the flexibility to upgrade to 48 ports by purchasing the N9K-EX-24P-UPG license.

Q: What NX-OS software version is required for this switch?
A: The Nexus 93108TC-EX-24 requires NX-OS version 9.3(2) or above. Always refer to the latest Cisco software compatibility matrix for recommended releases.

Q: Can this switch be used in Cisco ACI fabric mode?
A: Yes, the switch supports both standalone NX-OS mode and Cisco ACI fabric mode, allowing deployment in traditional or policy-driven software-defined data center architectures.

Q: Does this model support Power over Ethernet?
A: No, the N9K-C93108TC-EX-24 does not support PoE. It is designed for data center server and storage connectivity where PoE is not required.

Q: What Layer 3 features are supported?
A: With the appropriate NX-OS Essentials or Advantage license, the switch supports IPv4/IPv6 unicast routing (OSPF, BGP, EIGRP), multicast routing (PIM, IGMP), VXLAN EVPN, VRF-Lite, and advanced data center features.
