• Cisco Catalyst 3850 switch stack with N540-PWR750-A 750W AC PSU
1 1

Cisco

Cisco N540-PWR750-A | NCS 540 750W AC Power Supply, Hot-Swappable

N540-PWR750-A

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The N540-PWR750-A is a hot-swappable 750W AC power supply module for the Cisco Network Convergence System 540 (NCS 540) range. It is listed as the AC power supply for the NCS 540 Fronthaul Aggregation Router (N540-FH-AGG-SYS), used in mobile transport and 5G fronthaul or aggregation sites.

This is the AC input version, accepting 100-240 VAC at 50/60 Hz, which makes it suitable for worldwide AC deployments. Its DC counterpart is the N540-PWR750-D, so choose this -A model where the site supplies mains AC. The aggregation chassis it serves draws up to 700W at maximum load, and two supplies can be installed together for 1+1 power redundancy.

Being field-replaceable and hot-swappable, a PSU can be exchanged without taking the router out of service when a redundant pair is fitted. It is typically ordered alongside the N540-FAN-FHA fan assembly and N540-RKM rack mounting kits for the same chassis.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swappable, field-replaceable power supply
- Supports 1+1 power redundancy when two units are installed
- Wide-range AC input for worldwide deployment
- AC input version, with a separate DC model available (N540-PWR750-D)
- Suited to mobile transport and 5G fronthaul and aggregation sites

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: N540-PWR750-A
- Type: AC power supply module
- Output rating: 750W
- Input: 100-240 VAC, 50/60 Hz
- Hot-swappable: Yes
- Redundancy: 1+1 with two power supplies installed
- Listed chassis: NCS 540 Fronthaul Aggregation Router (N540-FH-AGG-SYS)
- Chassis airflow: Front-to-back
- DC equivalent: N540-PWR750-D

FAQs

Q: Which Cisco chassis is the N540-PWR750-A listed for?
A: It is listed as the AC power supply for the NCS 540 Fronthaul Aggregation Router (N540-FH-AGG-SYS). The Fronthaul Cell Site Router uses the N540-PWR400 power supplies instead.

Q: Is this the AC or DC power supply?
A: This is the AC version, accepting 100-240 VAC at 50/60 Hz. The DC version is the N540-PWR750-D.

Q: Can I run two power supplies for redundancy?
A: Yes. The chassis supports 1+1 power redundancy with two hot-swappable power supplies installed.

Q: Does this power supply need a licence?
A: No licence is needed for the power supply itself. Feature licences for Cisco IOS XR on the NCS 540 router are ordered separately for the chassis.

Q: How much power does the host router draw?
A: The NCS 540 Fronthaul Aggregation Router draws under 650W minimum, under 675W typical and up to 700W maximum, which sits within the 750W rating of this supply.
