Cisco N540-PKG-CVR | NCS 540 Meerkat Protection Cover for N540-8Z12G-SYS-D

N540-PKG-CVR

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The N540-PKG-CVR is the Meerkat protection cover for the Cisco NCS 540 series, the optional top cover also known as the NEBS kit. It suits the passively cooled NCS 540 Meerkat small density router chassis in rack-mounted indoor or cabinet deployments where improved airflow around the chassis is wanted.

Cisco lists this part under the F2B plenum accessories for the N540-8Z12G-SYS-D, a 2.5 RU, fanless router measuring 445 mm wide by 384 mm deep and weighing 10 kg. The cover is a passive mechanical accessory, so it needs no licence and draws no power. It attaches to the chassis with M3 screws and is fitted as the first step of the rack-mount procedure, before the rack-mount brackets and cable guides go on.

Companion accessories for the same chassis include the N540-RCKMT-19-MRK and N540-RCKMT-23-MRK rack mounts and the A920-CBL-GUIDE-PC cable bracket.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Optional top cover and NEBS kit for the NCS 540 Meerkat chassis
- Improves airflow around the passively cooled chassis
- Fitted with M3 screws before the rack-mount brackets and cable guides
- Passive mechanical design with no power draw
- Listed by Cisco under the F2B plenum accessories for the N540-8Z12G-SYS-D

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: N540-PKG-CVR
- Description: NCS540-Meerkat Protection Cover
- Product type: Router accessory, protection cover (NEBS kit)
- Datasheet category: F2B Plenum Accessories
- Listed accessory for: N540-8Z12G-SYS-D
- Host chassis form factor: 2.5 RU, 445 mm W x 384 mm D
- Host chassis weight: 10 kg
- Host chassis cooling: Fanless, passively cooled
- Host chassis mounting options: 19 inch and 23 inch
- Host chassis operating temperature: -20 to +65 C at 300 m (I-Temp)
- Attachment: M3 screws to the chassis
- Installation: Fitted before the rack-mount brackets
- Power: None, passive mechanical accessory
- Licensing: None required

FAQs

Q: Does the N540-PKG-CVR need a licence?
A: No. It is a passive mechanical accessory and requires no licence or software.

Q: Which chassis is this cover listed for?
A: Cisco lists it as an accessory for the N540-8Z12G-SYS-D, a 2.5 RU fanless NCS 540 small density router.

Q: Does it need power?
A: No. It is a passive cover with no power connection or power draw.

Q: How is it fitted?
A: It attaches to the chassis with M3 screws. This is done first, before the rack-mount brackets are installed.

Q: What other accessories are used with this chassis?
A: Companion parts for the N540-8Z12G-SYS-D include the N540-RCKMT-19-MRK and N540-RCKMT-23-MRK rack mounts and the A920-CBL-GUIDE-PC cable bracket.
