Cisco MEM-C8200L-8GB | Catalyst 8200L 8GB DDR4 DRAM Memory Module

MEM-C8200L-8GB

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This 8 GB DDR4 DRAM memory module is an upgrade for the Cisco Catalyst 8200L Edge platform (C8200L-1N-4T). The router ships with 4 GB of DRAM by default, and this module raises that to 8 GB. It suits branch and WAN edge deployments that run SD-WAN controller mode, embedded applications or ThousandEyes agents.

The module is a single 8 GB DIMM and replaces the DIMM in the platform's DIMM slot, so no other hardware change is needed. Cisco recommends 8 GB for feature-rich, high-scale environments to avoid high memory utilisation in controller mode, and 8 GB is the minimum DRAM required for ThousandEyes on the platform.

The C8200L-1N-4T also supports 16 GB and 32 GB DRAM options if you need further headroom. The module is passive and draws power from the host chassis, and it needs no licence of its own.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Raises C8200L memory from the default 4 GB to 8 GB, giving more headroom for control plane scale and embedded applications
- Recommended by Cisco for feature-rich, high-scale environments to avoid high memory utilisation in controller mode
- Meets the 8 GB DRAM minimum for ThousandEyes on the platform
- Replaces the DIMM in the platform's DIMM slot with no other hardware change needed
- Platform also supports 16 GB and 32 GB DRAM for future growth

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: MEM-C8200L-8GB
- Capacity: 8 GB
- Memory technology: DRAM (DDR4)
- Module configuration: 1 x 8 GB DIMM
- Product type: RAM module (system-specific upgrade)
- Compatible platform: Cisco Catalyst 8200L Edge (C8200L-1N-4T)
- Default DRAM on C8200L-1N-4T: 4 GB
- Supported DRAM options on C8200L-1N-4T: 8 GB, 16 GB and 32 GB
- Power: passive DIMM, drawn from the host chassis
- Licence: none required for the module

FAQs

Q: Does this memory module need a licence?
A: No. The module itself needs no licence or subscription. The host router uses Cisco DNA subscription licensing as normal.

Q: Which router does this memory fit?
A: It is for the Cisco Catalyst 8200L Edge platform (C8200L-1N-4T). That model ships with 4 GB of DRAM, so this module is an upgrade to 8 GB.

Q: Does it need separate power?
A: No. It is a passive DIMM and draws power from the host chassis.

Q: When do I need 8 GB instead of the default 4 GB?
A: Cisco recommends 8 GB for feature-rich, high-scale environments, including controller mode. 8 GB is also the minimum DRAM for ThousandEyes on this platform.

Q: Can the C8200L take more than 8 GB?
A: Yes. The C8200L-1N-4T supports 8 GB, 16 GB and 32 GB DRAM options.
