• Cisco MEM-4320-4GU8G DRAM 8GB upgrade with 32MB memory card
1 1

Cisco

Cisco MEM-4320-4GU8G | ISR 4320 8GB DRAM Memory Upgrade, 4G to 8G DIMM

MEM-4320-4GU8G

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This memory upgrade is designed for the Cisco ISR 4320 series, covering the ISR 4321 in the Cisco 4000 Series Integrated Services Routers family. It adds a single 4 GB DIMM to the router's fixed 4 GB of onboard DRAM, giving 8 GB of total system memory. It suits branch deployments that run routing, VPN and security services and need more memory headroom.

The upgrade takes the system from 4 GB to 8 GB DRAM. The ISR 4320 ships with 4 GB soldered to the motherboard, and this module adds 1 x 4 GB on top of that, which is the maximum DRAM supported on the ISR 4321. The memory is DDR3 ECC. The ISR 4321 has one DIMM slot, so this is a straightforward single-module install. No licence is required for the memory itself.

For services that need at least 8 GB DRAM, such as Snort IPS, this upgrade provides the extra capacity. It works with the ISR 4320 series, and the MEM-FLSH-4U8G 4G to 8G eUSB flash upgrade is the recommended companion so core dumps can be stored.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Simple single-DIMM upgrade path from 4 GB to 8 GB
- Complements the fixed 4 GB onboard memory
- Gives more headroom for services such as Snort IPS, VPN and routing tables
- Reaches the maximum 8 GB DRAM supported on the ISR 4321
- Pairs with the MEM-FLSH-4U8G flash upgrade so core dumps can be stored

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: MEM-4320-4GU8G
- Description: 4G to 8G DRAM Upgrade (Fixed 4G + additional 4G) for ISR4320
- Total DRAM after upgrade: 8 GB
- Default DRAM on ISR 4320: 4 GB soldered on motherboard (MEM-4320-4G)
- Added module: 1 x 4 GB DIMM
- Maximum DRAM on ISR 4321: 8 GB
- Memory type: DDR3 ECC
- DIMM slots on ISR 4321: 1
- Compatible platform: Cisco ISR 4320 series (ISR4321)
- Recommended companion flash upgrade: MEM-FLSH-4U8G (4G to 8G eUSB flash upgrade for ISR 4300)

FAQs

Q: How much memory does the ISR 4320 have after this upgrade?
A: The router has 8 GB of total DRAM. This is the 4 GB fixed onboard memory plus the 1 x 4 GB DIMM added by this upgrade, which is the maximum supported on the ISR 4321.

Q: Do I need a licence for this memory upgrade?
A: No. The memory module itself does not require a licence.

Q: Which routers is this memory upgrade for?
A: It is for the Cisco ISR 4320 series, including the ISR 4321. The ISR 4321 has a single DIMM slot, which this module uses.

Q: Should I upgrade the flash storage as well?
A: Cisco recommends pairing this DRAM upgrade with MEM-FLSH-4U8G, the 4G to 8G eUSB flash upgrade for the ISR 4300, so that core dumps can be stored.

Q: Why upgrade from 4 GB to 8 GB DRAM?
A: The extra memory gives more headroom for branch routing, VPN and security services. Some services, such as Snort IPS, call for at least 8 GB of DRAM.
