• Cisco ASR1000 RP3 32GB DRAM memory upgrade with 4x8GB modules
1 1

Cisco

Cisco M-ASR1K-RP3-32GB | ASR 1000 RP3 32GB (4x8GB) DRAM Memory Upgrade

M-ASR1K-RP3-32GB

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This 32 GB DRAM memory kit is built for the Cisco ASR 1000 Series Route Processor 3 (ASR1000-RP3). It is made up of four 8 GB DIMMs and raises the RP3 from its default 8 GB, giving more headroom for control-plane and routing-table memory. It suits ASR 1000 Series routers used in high-scale aggregation, WAN edge and service-provider deployments.

The kit populates all four RP3 DIMM slots, Ch-A DIMM0 and DIMM1 and Ch-B DIMM0 and DIMM1, with 8 GB each for 32 GB in total. The RP3 supports memory options up to 64 GB DRAM, so this configuration sits partway along the upgrade path and lets you scale memory as your needs grow. The modules are passive and draw power from the host route processor, so no separate power supply is required.

This memory is for the ASR1000-RP3 only. Memory from the RP2 cannot be reused on the RP3. When upgrading from the default 8 GB, all existing DIMMs are removed and the new set is installed, which avoids mismatched-DIMM issues.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Pay-as-you-grow memory scalability for the RP3, up to 64 GB DRAM
- Four 8 GB DIMMs populate all RP3 memory slots for 32 GB total
- Field-replaceable DIMM upgrade for the ASR1000-RP3 module
- Replacing the full DIMM set avoids mismatched-DIMM issues
- Passive modules powered by the host route processor

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: M-ASR1K-RP3-32GB (spare orderable as M-ASR1K-RP3-32GB=)
- Memory capacity: 32 GB (4 x 8 GB DIMMs)
- Ch-A DIMM0: 8 GB
- Ch-A DIMM1: 8 GB
- Ch-B DIMM0: 8 GB
- Ch-B DIMM1: 8 GB
- Compatible route processor: Cisco ASR1000-RP3
- RP3 default memory: 8 GB
- RP3 maximum memory: 64 GB
- RP3 CPU: Quad-core processor, 2.2 GHz
- RP3 built-in eUSB/eMMC bootflash: 8 GB
- Memory reuse: RP2 memory cannot be reused on RP3

FAQs

Q: Which route processor does this memory work with?
A: It is for the Cisco ASR1000-RP3 Route Processor 3 only. Memory from the RP2 cannot be reused on the RP3.

Q: How much memory does the RP3 support in total?
A: The RP3 supports memory options up to 64 GB DRAM. This kit provides 32 GB as four 8 GB DIMMs, up from the RP3 default of 8 GB.

Q: Can I add this kit alongside the existing DIMMs?
A: No. When upgrading from 8 GB, all existing DIMMs are removed and the new set of four DIMMs is installed, which avoids mismatched-DIMM issues.

Q: Does the memory need its own power supply?
A: No. The DIMMs are passive modules powered by the host ASR1000-RP3 route processor.
