Cisco M-ASR1K-RP3-16GB | ASR 1000 RP3 16GB (2x8GB) DRAM Memory Module

M-ASR1K-RP3-16GB

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The M-ASR1K-RP3-16GB is a 16 GB DRAM memory option for the Cisco ASR 1000 Series Route Processor 3 (ASR1000-RP3). It is populated as two 8 GB DIMMs and lifts the RP3 from its default 8 GB of memory, giving carrier-grade IP/MPLS aggregation, WAN edge and Internet edge deployments more headroom for larger routing tables, additional VRFs and heavier feature loads.

With 16 GB fitted, the RP3 supports up to 4,000,000 IPv4 or IPv6 routes, and BGP route reflector scale of up to 24,000,000 IPv4 routes or 17,000,000 IPv6 routes. The two 8 GB DIMMs occupy Channel A DIMM0 and Channel B DIMM0. The RP3 itself offers upgrade options of 16, 32 or 64 GB, so this module suits a pay-as-you-grow approach to memory.

This module is for the ASR1000-RP3 only, used in ASR 1006-X, 1009-X and 1013 chassis running Cisco IOS XE 16.3.1 or later. It is passive, is powered from the route processor, and needs no licence. It is not interchangeable with the RP2 memory options or the fixed-chassis ASR 1001 memory options.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Pay-as-you-grow memory scalability on the RP3, up to 64 GB
- Supports routing-table growth, additional MPLS VPN VRFs and features such as SBC and BBA
- Field-installable DIMM upgrade for the RP3 route processor
- RP3 supports redundant route processors with ISSU, NSF and SSO
- RP3 runs 64-bit Cisco IOS XE

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: M-ASR1K-RP3-16GB (spare: M-ASR1K-RP3-16GB=)
- Memory capacity: 16 GB DRAM
- DIMM configuration: 2 x 8 GB (Ch-A DIMM0 and Ch-B DIMM0 populated)
- Host route processor: Cisco ASR1000-RP3
- RP3 default memory: 8 GB, upgradable to 16, 32 or 64 GB
- Supported chassis: ASR 1006-X, ASR 1009-X, ASR 1013
- Minimum software: Cisco IOS XE 16.3.1
- RP3 performance with 16 GB: up to 4,000,000 IPv4 routes or 4,000,000 IPv6 routes
- RP3 BGP RR scalability with 16 GB: up to 24,000,000 IPv4 routes or 17,000,000 IPv6 routes
- RP3 CPU: Quad-core processor, 2.2 GHz
- RP3 built-in bootflash: 8 GB eUSB/eMMC
- RP3 operating temperature, nominal: 5 to 40 C
- RP3 reliability: 1+1 redundancy, OIR, NSF/SSO, ISSU

FAQs

Q: Does this memory module need a licence?
A: No. No licence is required for the memory module itself.

Q: Which route processor does it fit?
A: It is for the Cisco ASR1000-RP3 only, used in ASR 1006-X, 1009-X and 1013 chassis running IOS XE 16.3.1 or later.

Q: Can I use it in an RP2 or an ASR 1001?
A: No. It is not interchangeable with the RP2 memory options (M-ASR1K-RP2-8GB/16GB) or the fixed-chassis ASR 1001 memory options.

Q: Does it need its own power supply?
A: No. It is a passive module powered from the RP3 route processor and the ASR 1000 chassis.

Q: How much memory can the RP3 take in total?
A: The RP3 supports 8, 16, 32 or 64 GB of DRAM. This module provides 16 GB as two 8 GB DIMMs, upgrading the default 8 GB.
