Cisco M-ASR1002X-16GB | ASR1002-X 16GB (4x 4GB) DRAM Memory Module

M-ASR1002X-16GB

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This 16GB DRAM memory option is made for the Cisco ASR1002-X router in the ASR 1000 Series Aggregation Services Routers family. It is a field-replaceable upgrade to the router's built-in route processor memory, which ships with 4GB by default, and suits WAN aggregation and edge deployments that need more routes, sessions and features than the default allows.

The kit is 16GB made up of 4 x 4GB modules, filling all 4 DRAM slots on the ASR1002-X route processor. 16GB is the maximum memory the ASR1002-X supports, so this upgrade takes the platform to its full memory scalability. The memory draws power from the host chassis, so no separate power supply is needed, and no licence is required for the module itself.

This part is platform-specific and is intended for the ASR1002-X only. It is not for other ASR 1000 models such as the ASR1001-X or ASR1002-HX, or for the RP2 and RP3 route processors, which use different memory parts.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Raises ASR1002-X route processor memory to its 16GB maximum
- Fills all 4 DRAM slots with 4 x 4GB modules
- Field-replaceable, so no chassis replacement is needed
- Supports the memory scalability stated for the ASR 1000 route processor
- Suits the ASR1002-X Base, HA, Security, VPN and 10G HA bundles
- Increases capacity for larger route tables, more sessions and more enabled features

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: M-ASR1002X-16GB
- Type: DRAM
- Capacity: 16GB (4 x 4GB modules)
- Memory slots used: 4 of 4 on the ASR1002-X route processor
- Compatible platform: Cisco ASR1002-X only
- Upgrade type: System specific, field-replaceable unit (FRU)
- ASR1002-X default memory: 4GB (2 x 2GB)
- ASR1002-X maximum memory: 16GB
- Licence required: None
- Power: Drawn from the host ASR1002-X chassis

FAQs

Q: Which routers is this memory compatible with?
A: It is for the Cisco ASR1002-X only, which has a built-in route processor with 4 DRAM slots. It is not for the ASR1001-X, ASR1002-HX or the RP2 and RP3 route processors, which use different memory parts.

Q: Do I need a licence for this memory upgrade?
A: No. The memory module itself does not require a licence.

Q: How much memory does the ASR1002-X support in total?
A: The ASR1002-X ships with 4GB by default and supports a maximum of 16GB. This 16GB kit takes the router to that maximum.

Q: Does it need a separate power supply?
A: No. The memory draws power from the host ASR1002-X chassis.

Q: Do I need to replace the chassis to install it?
A: No. It is a field-replaceable unit, so it upgrades the existing route processor memory without replacing the chassis.
