Cisco

Cisco ISM-SRE-300-K9 | SRE 300 ISM Application Engine Module, 4GB Flash

ISM-SRE-300-K9

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco SRE 300 Internal Service Module is a Services-Ready Engine blade for Cisco ISR G2 routers. It installs inside the router chassis and hosts Cisco, third-party and custom branch-office applications on its own processor, memory and flash storage, independent of the host router's resources. It suits branch-office and small-to-medium enterprise sites looking to consolidate separate servers or appliances onto the router.

The SRE 300 ISM uses a 1.06 GHz Intel processor with 512 MB DRAM and a 4 GB internal USB flash memory module. There is no hard disk and no RAID support. Connectivity to the router backplane is Gigabit Ethernet, with no external network interfaces. Maximum power consumption is 20 W, drawn from the host router chassis, so no separate power supply is needed.

It is supported on Cisco 1941, 2901, 2911, 2921, 2951, 3925 and 3945 ISR G2 routers, with one ISM per chassis, and needs router IOS Release 15.0(1)M or later. It is not supported on the 3925E or 3945E. Typical roles include an entry-level Wireless LAN Controller supporting up to 10 access points, Cisco Unity Express voicemail, or custom applications on Cisco AXP. The module hardware needs no licence, while applications are licensed separately.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hosts Cisco, third-party and custom applications on a module independent of router resources
- On-demand remote application provisioning, at install time or later
- Installs inside the router with no extra cables, switch ports or power cords
- Remote power-on and power-off capability to reduce power use when idle
- Managed through Cisco Configuration Professional, the CLI and CiscoWorks LMS
- Onboard hardware diagnostic tool for health monitoring and troubleshooting
- As a Wireless LAN Controller host, supports up to 10 access points

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Form factor: Internal Service Module (ISM)
- CPU: Intel processor, 1.06 GHz
- DRAM: 512 MB
- Flash memory: 4 GB internal USB flash memory module
- Hard disk: None
- RAID support: None
- Internal network interface: Gigabit Ethernet to router backplane
- External network interfaces: None
- Router platforms: Cisco 1941, 2901, 2911, 2921, 2951, 3925 and 3945 ISR G2
- Modules per chassis: 1 ISM
- Router software: Cisco IOS Release 15.0(1)M or later
- Hardware cryptography acceleration: No
- Supported applications: Cisco Unity Express, Cisco Application Extension Platform (AXP), Cisco Wireless LAN Controller (WLC)
- Maximum power consumption: 20 W
- Dimensions (H x W x D): 2.2 x 10.2 x 15.5 cm
- Maximum weight: 0.206 kg
- Storage and transport temperature: -25 to 70 C
- Storage and transport relative humidity: 5 to 95%
- Storage and transport altitude: 4,600 m
- EMC: Class A, including AS/NZS CISPR 22 Class A, FCC Part 15 Class A, EN55022, EN55024

FAQs

Q: Does the SRE 300 ISM need a licence?
A: The module hardware needs no licence. Applications are licensed separately, for example Wireless LAN Controller on SRE access-point licences (FL-SRE-WLC-5 or FL-SRE-WLC-25), with capacity capped at 10 access points on this module.

Q: Which routers is the SRE 300 ISM compatible with?
A: It is supported on Cisco 1941, 2901, 2911, 2921, 2951, 3925 and 3945 ISR G2 routers, with one ISM per chassis. It is not supported on the 3925E or 3945E and needs router IOS Release 15.0(1)M or later.

Q: Does it need its own power supply?
A: No. It draws power from the host ISR G2 router chassis, with a maximum consumption of 20 W.

Q: How does it differ from other SRE modules?
A: The SRE 300 ISM has 512 MB DRAM and a 4 GB flash module with no hard disk, and it installs in the router's internal service module slot.

Q: Which management tools are supported?
A: It is managed through the router CLI, Cisco Configuration Professional 2.0 or later, and CiscoWorks LMS 3.2 or later.
