• Cisco IE-3100-8T4S-E 8-port Gigabit Ethernet switch with 4 SFP uplinks
1 1

Cisco

Cisco IE-3100-8T4S-E | Catalyst IE3100 Rugged 8-Port Gigabit Industrial Switch, 4x 1G SFP

IE-3100-8T4S-E

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Cisco IE-3100-8T4S-E is a compact, ruggedized industrial Ethernet switch delivering 8 Gigabit copper ports and 4 SFP uplinks for harsh environment deployments. Built for manufacturing, transportation, energy, and smart city applications, it operates across extended temperature ranges and features DIN-rail mounting. Powered by Cisco IOS XE with Network Essentials licensing, it provides advanced security, industrial protocol support, and seamless integration with Cisco Catalyst Center for centralized management.

Features

Cisco IOS XE operating system with built-in security, Secure Boot, and Cisco Trust Anchor module
- Layer 2 switching with VLAN support (up to 256 VLANs)
- Quality of Service (QoS) for traffic prioritization
- Industrial protocol support: EtherNet/IP (CIP), Modbus, PROFINET
- IEEE 1588v2 Precision Time Protocol (PTP) for time synchronization
- Resilient Ethernet Protocol (REP) and Media Redundancy Protocol (MRP)
- Rapid Spanning Tree Protocol (RSTP) and Multiple Spanning Tree Protocol (MSTP)
- 802.1X authentication, MAC Authentication Bypass (MAB), and Access Control Lists (ACLs)
- Zero Trust Network Access (ZTNA) with Cisco Secure Equipment Access
- SD-Access extended node capability
- Cisco Catalyst Center integration for centralized management
- WebUI for simplified configuration and monitoring
- API-driven configuration with open APIs and data models (NETCONF, RESTCONF, YANG)
- Zero-touch provisioning and swap drive replacement
- Removable SD card for configuration storage and rapid field replacement
- Dual redundant DC power inputs (12-48V nominal, 9.6-60V absolute)
- Two dry-contact alarm inputs for environmental monitoring
- RS-232 console port (RJ-45) and Micro USB console port
- Fanless, ruggedized design for harsh environments
- DIN-rail mountable for industrial cabinets
- Extended temperature range: -40°C to +75°C
- Conformal coating option for additional environmental protection

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Manual

Technical Specifications

Total Ports: 12 (8x 10/100/1000 RJ-45 + 4x 1G SFP uplinks)
- Switching Capacity: 12 Gbps
- Forwarding Rate: 17.856 Mpps
- MAC Address Table: 8,000 entries
- VLAN Support: 256 VLANs
- Memory: 4 GB DRAM, 1.5 GB Flash
- Operating System: Cisco IOS XE
- License Level: Network Essentials
- Management: WebUI, CLI, Cisco Catalyst Center, SNMP, NETCONF/RESTCONF APIs
- Power Input: DC 12-48V nominal (9.6-60V absolute), dual redundant inputs
- Power Consumption: 17.8W typical
- Operating Temperature: -40°C to +75°C (-40°F to +167°F)
- Storage Temperature: -40°C to +85°C (-40°F to +185°F)
- Humidity: 5% to 95% non-condensing
- Mounting: DIN-rail, compact form factor
- Dimensions (H x W x D): 5.00 x 3.00 x 4.33 in (12.70 x 7.62 x 11.00 cm)
- Weight: 1.9 lb (0.86 kg)
- MTBF: 575,966 hours
- Certifications: Industrial hardened, conformal coating option available

FAQs

Q: What industrial protocols does the IE-3100-8T4S-E support?
A: The switch natively supports EtherNet/IP (CIP), Modbus, PROFINET, and IEEE 1588v2 PTP for seamless integration with industrial automation and SCADA systems.

Q: Can this switch operate in extreme temperatures?
A: Yes, the IE-3100-8T4S-E operates from -40°C to +75°C and is designed for harsh environments including manufacturing plants, outdoor cabinets, and utility substations. It features fanless cooling and vibration resistance.

Q: Does this model support Power over Ethernet (PoE)?
A: No, the IE-3100-8T4S-E does not support PoE. It is a non-PoE model designed for data connectivity. For PoE requirements, consider the IE-3100-4P2S-E or IE-3100-8P2C-E models in the same series.

Q: What redundancy and resiliency features are included?
A: The switch includes dual redundant DC power inputs, support for Resilient Ethernet Protocol (REP) and Media Redundancy Protocol (MRP), and fast convergence with RSTP/MSTP for continuous operation and minimal downtime.

Q: How is the IE-3100-8T4S-E managed and deployed?
A: The switch can be managed via Cisco Catalyst Center, WebUI, CLI, SNMP, or NETCONF/RESTCONF APIs. It supports zero-touch provisioning and includes a removable SD card for configuration swap and rapid replacement.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.

Manual

This product has a detailed PDF manual available. Open PDF manual in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.
