Cisco HX-GPU-RTX6000 | RTX 6000 Graphics Card, 24GB GDDR6, 4608 CUDA Cores

HX-GPU-RTX6000

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.

Description

The Cisco HX-GPU-RTX6000 is an NVIDIA Quadro RTX 6000 passive graphics card designed for UCS and HyperFlex servers. Built on the Turing architecture with 4608 CUDA cores, 576 Tensor cores, and 72 RT cores, it accelerates AI, deep learning, rendering, and virtualized workstation workloads in data center environments. The 24GB GDDR6 memory and passive thermal design enable high-density GPU deployments for demanding visual computing and scientific applications.

Features

NVIDIA Turing GPU architecture with dedicated RT cores for hardware-accelerated ray tracing
- 4608 parallel CUDA cores for compute-intensive workloads
- 576 Tensor cores for AI training and inference acceleration
- 72 RT cores deliver real-time photorealistic rendering
- 24GB GDDR6 ECC memory handles large datasets and complex models
- 672 GB/s memory bandwidth for high-throughput data processing
- PCIe 3.0 x16 interface for broad server compatibility
- Passive thermal design optimized for data center rack servers
- NVLink support enables dual-GPU configurations with 48GB combined memory
- NVIDIA Quadro vDWS software support for virtual workstation deployment
- ISV certified for professional applications including Autodesk, SolidWorks, and Adobe
- 16.3 TFLOPS single-precision (FP32) and 32.6 TFLOPS half-precision (FP16) performance
- Supports CUDA, OpenCL, DirectX 12, Vulkan, and OpenGL APIs
- Dual-slot form factor with 250W TGP

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

GPU Architecture: NVIDIA Turing
- CUDA Cores: 4608
- Tensor Cores: 576 (AI acceleration)
- RT Cores: 72 (hardware ray tracing)
- Memory: 24GB GDDR6 with ECC
- Memory Interface: 384-bit
- Memory Bandwidth: 672 GB/s
- System Interface: PCIe 3.0 x16
- TGP (Total Graphics Power): 250W
- Thermal Solution: Passive heatsink (requires server airflow)
- Form Factor: Dual-slot, full-height
- NVLink Support: Yes (scalable to 48GB with dual GPUs)
- FP32 Performance: 16.3 TFLOPS
- FP16 Performance: 32.6 TFLOPS

FAQs

Q: Which Cisco servers support the HX-GPU-RTX6000?
A: This GPU is compatible with Cisco UCS C240 M5, UCS C220 M5, and HyperFlex HX240c M5/HX220c M5 servers. It requires appropriate PCIe riser configuration and adequate server airflow for passive cooling. Check your server's configuration guide for maximum GPU capacity and power requirements.

Q: What workloads benefit most from the RTX 6000?
A: The RTX 6000 excels at AI model training and inference, GPU-accelerated rendering, virtualized desktop infrastructure (VDI), CAD/simulation, scientific visualization, and video processing. The 72 RT cores enable real-time ray tracing, while 576 Tensor cores accelerate deep learning frameworks.

Q: Does this passive GPU require special cooling considerations?
A: Yes, passive GPUs rely entirely on server chassis airflow for cooling. Ensure your server has adequate front-to-back airflow, functioning fans, and proper PCIe slot spacing. Do not use in systems without active cooling or with blocked ventilation.

Q: Can I connect displays directly to this GPU?
A: This passive server variant is designed for compute and virtualized graphics workloads via NVIDIA Quadro vDWS (Virtual Data Center Workstation) software. It does not have display connectors; graphics output is delivered over the network to thin clients or virtual workstations.

Q: Is NVLink supported for multi-GPU configurations?
A: Yes, the RTX 6000 supports NVLink connectivity. Two GPUs can be linked with an NVIDIA Quadro RTX NVLink HB bridge to combine 48GB memory and scale bandwidth up to 100 GB/s, ideal for large-scale AI training and rendering tasks.
