Cisco

Cisco HWIC-2CE1T1-PRI | 2x T1/E1 Channelized + ISDN PRI HWIC | RJ-48C | CSU/DSU | T1: 1.544M ESF/SF B8ZS/AMI | E1: 2.048M G.704 HDB3 | NxDS0 (1–24/31)

SKU:HWIC-2CE1T1-PRI

Regular price POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

Dual-port channelized T1/E1 interface for routers, combining ISDN PRI and fractional data on each port. Configure each port independently for T1 or E1, leverage the integrated CSU/DSU for line build-out and clocking, and terminate voice PRI trunks or NxDS0 circuits. Standards-based framing/coding over RJ-48C ensures easy interop with telco and PBX environments. Ideal for multi-trunk voice gateways and branch WAN aggregation.

Features

- Two independently configurable T1/E1 ports for flexible deployments
- ISDN PRI and channelized data on each port
- Integrated CSU/DSU simplifies wiring and reduces cost
- Standards-compliant framing and coding for carrier interop
- RJ-48C interfaces for direct telco demarc connections

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details
  • You may also like
  • Best sellers
  • Related Products

specs-tabs

Collapsible content

FAQs

Technical Specifications

FAQs

Q: Are the two ports independently configurable?
A: Yes. Each port can be set to T1 or E1 and configured for PRI or channelized data.

Q: Does it support ISDN PRI on both ports simultaneously?
A: Yes, both ports support ISDN PRI (subject to router performance and IOS).

Q: Is an external CSU/DSU needed?
A: No. The module includes an integrated CSU/DSU on each port.

Q: Can I use fractional NxDS0 data circuits?
A: Yes. You can allocate any subset of timeslots (1–24 for T1, 1–31 for E1).

Q: What connector type is used?
A: RJ-48C on each port, using 100Ω (T1) or 120Ω (E1) twisted pair.

Technical Specifications

- Ports: 2 x T1/E1, channelized (independent configuration)
- ISDN PRI: Supported on both ports
- Per-port mode: Selectable T1 or E1
- Line rate: T1 1.544 Mbps; E1 2.048 Mbps per port
- Timeslots: T1 1–24; E1 1–31; Nx56/Nx64 kbps
- Framing: T1 ESF or SF (D4); E1 G.704 (CRC4/non-CRC)
- Line coding: T1 AMI or B8ZS; E1 HDB3
- Connectors: 2 x RJ-48C
- Integrated CSU/DSU with line build-out and line/internal clocking
- Use cases: Voice PRI trunking, multi-link branch WAN, fractional data
- Alarm/status reporting via router IOS
- Form factor: HWIC (requires router with available HWIC slot)
