Cisco

Cisco FPR3K-XNM-6X1SXF | 6x 1GbE SX fiber ports | 1000BASE-SX MMF 850nm, up to 550m, LC | XNM expansion module for Secure Firewall 3100

SKU:FPR3K-XNM-6X1SXF

Regular price POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

Add six high-density 1G fiber interfaces to your Secure Firewall 3100 appliance with this SX multimode XNM module. Fixed 1000BASE-SX optics provide LC connectivity for campus and data center aggregation, ideal for short-reach MMF uplinks and segmentation.

Features

- Six integrated 1G SX fiber ports for dense MMF connectivity
- Fixed 1000BASE-SX optics simplify deployment—no SFPs required
- LC duplex connectors with up to 550 m typical reach on OM3/OM4
- Hot-swappable XNM design for minimal downtime
- Optimized for Secure Firewall 3100 series interface expansion

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details
  • You may also like
  • Best sellers
  • Related Products

specs-tabs

Collapsible content

FAQs

Technical Specifications

FAQs

Q: Which appliances is this module compatible with?
A: It is designed for Secure Firewall 3100 series appliances that include an XNM network module bay.

Q: Does this module require SFP transceivers?
A: No. The ports are fixed 1000BASE-SX with integrated optics and LC connectors.

Q: Can these ports operate over single-mode fiber?
A: No. They are multimode 1000BASE-SX (850 nm) ports intended for MMF cabling.

Q: Is the module hot-swappable?
A: Yes, it is front-access and hot-swappable. Follow platform guidelines for insertion/removal.

Q: Can I mix this with other XNM modules?
A: You can populate the appliance’s XNM bay with the module option supported by your model; mixing is subject to the number of bays available on the specific chassis.

Technical Specifications

- Interface count: 6x 1 Gigabit Ethernet fiber ports
- Base standard: 1000BASE-SX (multimode fiber)
- Wavelength: 850 nm
- Connector: LC duplex
- Typical reach: up to 550 m on MMF (distance varies by fiber grade)
- Form factor: XNM network module for Secure Firewall 3100 series
- Hot-swappable: Yes (serviceable via front panel)
- Port features: VLANs, subinterfaces, and policy handled by firewall OS
- Supported cabling: OM2/OM3/OM4 MMF
- Compatibility: Secure Firewall 3100 platforms with an XNM bay
