Cisco

Cisco DS-CWDM-MUX-8 | CWDM 8‑ch Mux/Demux | 1470–1610 nm | LC/UPC | Passive | Chassis plug‑in

SKU:DS-CWDM-MUX-8

Regular price POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

Eight‑channel CWDM Mux/Demux plug‑in module for CWDM chassis systems. Consolidates up to eight wavelengths over a single pair of fibers to maximize capacity, with passive operation and LC/UPC single‑mode interfaces. Ideal for scaling metro, campus, and DCI links while remaining protocol agnostic across the CWDM grid.

Features

- Eight CWDM channels to maximize fiber capacity
- Passive, maintenance‑free operation
- Protocol‑agnostic transport across 1470–1610 nm
- LC/UPC SMF connectivity
- Chassis plug‑in form factor for neat integration
- Ideal for scalable metro, campus, and DCI architectures

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details
  • You may also like
  • Best sellers
  • Related Products

specs-tabs

Collapsible content

FAQs

Technical Specifications

FAQs

Q: How many services can this module carry?
A: Up to eight independent services, one per CWDM wavelength.

Q: Does it require any power or configuration?
A: No. It is a passive optical Mux/Demux and requires no power or software configuration.

Q: What connector and fiber type are used?
A: LC/UPC connectors on single‑mode fiber.

Q: Can different protocols and speeds be mixed?
A: Yes. CWDM is protocol agnostic, allowing mixed Ethernet, Fibre Channel, and other optical services simultaneously.

Q: Is it compatible with CWDM SFPs?
A: Yes. Use SFPs or optics that match the specific CWDM wavelengths populated on the module.

Technical Specifications

- Channels: 8 CWDM wavelengths (20 nm spacing, ITU‑T G.694.2)
- Operating band: 1470–1610 nm CWDM grid
- Function: Mux/Demux for bidirectional transport over single‑mode fiber
- Connector type: LC/UPC
- Fiber type: single‑mode (G.652 recommended)
- Design: passive (no external power required)
- Form factor: chassis plug‑in module
- Protocol agnostic: supports Ethernet, Fibre Channel, and other optical signals within optical budget
- Deployment: metro aggregation, campus backhaul, data center interconnect
