• Cisco CPAK-100G-PSM4 100G PSM4 SFP+ module with orange accents
1 1

Cisco

Cisco CPAK-100G-PSM4 | CPAK 100G PSM4 Transceiver, 500m SMF, MPO-12

CPAK-100G-PSM4

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco CPAK 100GBASE PSM4 module is a 100 Gigabit Ethernet transceiver built to the 100G PSM4 MSA. It carries 1x100G over 12-fibre parallel single-mode fibre with an MPO connector, which makes it a fit for high-density 100G links in enterprise and service provider data centres and at the service provider edge.

The module supports links of up to 500 m over G.652 single-mode fibre with a 9-micron core. It runs four lanes across a 1295 to 1325 nm wavelength range, with transmit power of -9.4 to +2.0 dBm and receive power of -12.7 to +2.0 dBm per lane. Power draw is below 9.0 W at 70 C, supplied by the host line card, and the operating range is 0 to 70 C. Digital Optical Monitoring is supported. No licence or subscription is required.

The CPAK form factor is 20% smaller and uses 40% less power than CFP2 modules. It is supported on Cisco ASR 1000 and ASR 9000 Series Routers, the CRS-X Carrier Routing System, NCS 2000, 4000 and 6000 Series Routers, Nexus 7000 and 7700 Series Switches, and the Cisco ONS Transport Platform. Link runs need a 12-fibre single-mode MPO cable.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- CPAK form factor is 20% smaller and uses 40% less power than CFP2 modules
- Up to 20% greater port density and front-panel bandwidth than competing products
- Digital Optical Monitoring (DOM) for module diagnostics
- Cisco quality ID lets the host platform identify certified and tested modules
- Supports a pay-as-you-grow deployment model
- Fits Cisco AnyPort, so 100G, 40G and 10G line cards can use CPAK modules
- Based on the 100G PSM4 MSA

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Product ID: CPAK-100G-PSM4
- Description: 100GBASE PSM4 Cisco CPAK Module for SMF
- Form factor: CPAK
- Supported mode: 1x100G
- Supported protocol: 100G PSM4 MSA
- Wavelength: 1295 to 1325 nm, four lanes
- Cable type: SMF, 12 fibres
- Core size: 9-micron core SMF per G.652
- Connector: MPO
- Cable distance: up to 500 m
- Transmit power: -9.4 to +2.0 dBm per lane
- Receive power: -12.7 to +2.0 dBm per lane
- Power consumption at 70 C: below 9.0 W maximum
- Operating temperature: 0 to 70 C (32 to 158 F)
- Storage temperature: -40 to 85 C (-40 to 185 F)
- Dimensions (H x W x D): 11.6 x 34.8 x 101.2 mm maximum
- Weight: approximately 127 g
- Digital Optical Monitoring: Supported

FAQs

Q: Does this module need a licence or subscription?
A: No. The CPAK-100G-PSM4 needs no licence or subscription. It works once seated in a supported host line card.

Q: What fibre and connector does it use?
A: It uses 12-fibre parallel single-mode fibre (G.652, 9-micron core) with an MPO connector, so you need a 12-fibre single-mode MPO cable. Reach is up to 500 m.

Q: Which Cisco platforms support this CPAK module?
A: It is supported on Cisco ASR 1000 and ASR 9000 Series Routers, the CRS-X Carrier Routing System, NCS 2000, 4000 and 6000 Series Routers, Nexus 7000 and 7700 Series Switches, and the Cisco ONS Transport Platform. Check the Cisco TMG compatibility matrix for exact platform and software support.

Q: How is the module powered?
A: It draws power from the host line card. Maximum power consumption is below 9.0 W at 70 C.

Q: How does this differ from other 100G CPAK modules?
A: This is the PSM4 variant, which runs 1x100G over 12-fibre parallel single-mode fibre with an MPO connector for links up to 500 m. Other CPAK variants use different standards, fibre types and connectors.
