Cisco

Cisco CPAK-100G-LR4-BR | CPAK 100G Transceiver, 10x10G LR Breakout, 10km SMF

CPAK-100G-LR4-BR

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This Cisco CPAK transceiver is a hot-swappable 100G optical module that runs in 10 x 10G mode over single-mode fibre. It suits network teams who need to break a single CPAK port out into ten 10GBASE-LR links of up to 10 km on Cisco routers, switches and optical transport platforms, giving high-density 10G fan-out and a clear path from 10G to 100G.

The module operates at 1310 nm over G.652 single-mode fibre and uses a 24-fibre MPO/MTP female APC connector. Each of the ten lanes carries 10G, with transmit power of -8.2 to 0.5 dBm and receive power of -14.4 to 0.5 dBm per lane. It supports IEEE 802.3ae, Fibre Channel and ITU OTU2, and Digital Optical Monitoring (DOM). Maximum power consumption is under 5.0 W at 70 C, and no licence or subscription is required for the module itself.

It plugs into CPAK ports on Cisco CPAK-based platforms and needs ribbon-to-duplex single-mode breakout cables (MPO-24 APC to duplex) to reach ten 10GBASE-LR interfaces. It can also be used in CFP2 ports through the CVR-CFP2-CPAK10 adapter.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Breaks a 100G CPAK port out into ten 10GBASE-LR links
- Up to 10 x 100GE connections deliver as much as 1 Tbps of front-panel bandwidth
- Uses 40% less power than CFP2 and 70% less than CFP form factors
- Hot-swappable for in-service replacement
- Digital Optical Monitoring (DOM) support
- Cisco ID lets the host platform identify certified and tested modules
- Supports the Cisco AnyPort pay-as-you-grow solution
- Interoperates with IEEE-compliant 10GBASE-LR interfaces via breakout cabling

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Form factor: CPAK, 100G aggregate (10 x 10G lanes)
- Mode: 10 x 10GBASE-LR breakout
- Supported standards: IEEE 802.3ae, Fibre Channel, ITU OTU2
- Wavelength: 1310 nm
- Fibre type: Single-mode, 24 fibres, 9-micron core, G.652
- Maximum distance: 10 km
- Connector: 24-fibre MPO/MTP, female APC
- Transmit power (per lane): -8.2 dBm min, 0.5 dBm max
- Receive power (per lane): -14.4 dBm min, 0.5 dBm max
- Lane wavelength range: 1260 to 1355 nm
- Host FEC: required in OTN mode
- Dimensions (H x W x D): 11.6 x 34.8 x 101.2 mm
- Weight: approx. 127 g
- Power consumption: under 5.0 W maximum at 70 C
- Operating temperature: 0 to 70 C
- Storage temperature: -40 to 85 C
- Monitoring: Digital Optical Monitoring (DOM)

FAQs

Q: Does this module need a licence or subscription?
A: No. The module itself needs no licence or subscription.

Q: What cabling does it need to connect to 10GBASE-LR interfaces?
A: It needs ribbon-to-duplex single-mode breakout cables, from an MPO-24 APC connector to duplex connectors, to reach ten 10GBASE-LR interfaces at up to 10 km.

Q: Which ports does it work in?
A: It plugs into CPAK ports on Cisco CPAK-based switches, routers and optical platforms. It can also be used in CFP2 ports through the CVR-CFP2-CPAK10 adapter. Check the Cisco 100 Gigabit Ethernet Transceiver Modules Compatibility Matrix for supported platforms and software.

Q: How much power does it draw?
A: It draws under 5.0 W at 70 C, supplied by the host CPAK port.

Q: Is host FEC required?
A: Host FEC is required when the module is operated in OTN mode.
