• Cisco CPAK-100G-LR4-2K 100GBASE-LR4 transceiver with RJ-45 connector
1 1

Cisco

Cisco CPAK-100G-LR4-2K | CPAK 100G LR4 Transceiver, 10km SC, OTU4 Dual Rate

CPAK-100G-LR4-2K

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The CPAK-100G-LR4-2K is a hot-swappable CPAK optical module for 100 Gbps links over duplex single-mode fibre. It suits enterprise and service provider data centres and service provider edge networks that need 100G reach of up to 10 km on CPAK-based switch, router and optical transport platforms.

The module is IEEE 802.3ba 100GBASE-LR4 compliant and carries four 25G LAN-WDM lanes around 1310 nm over G.652 single-mode fibre. It is a dual rate part supporting both 100G Ethernet and OTU4, and it terminates in dual SC/PC connectors, so use PC or UPC patch cords. Maximum power consumption is below 8.0 W at 70 C, drawn from the host CPAK port with no external supply. Digital Optical Monitoring is supported.

The datasheet lists ASR 1000 and ASR 9000 routers, CRS-X, NCS 2000, 4000 and 6000 platforms, Nexus 7000 and 7700 switches and the Cisco ONS Transport Platform. It interoperates with IEEE-compliant 100GBASE-LR4 optics. Confirm exact platform and software support in the Cisco Transceiver Module Compatibility Matrix.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swappable module for CPAK-based switch, router and optical platform ports
- Dual rate operation: 100G Ethernet and OTU4
- Digital Optical Monitoring (DOM) support
- CPAK form factor is about 20% smaller and uses about 40% less power than CFP2
- Cisco quality ID lets the host platform identify certified and tested modules
- Interoperates with IEEE-compliant 100GBASE-LR4 optics
- Supports the Cisco AnyPort pay-as-you-grow solution

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Form factor: Cisco CPAK
- Standard: IEEE 802.3ba 100GBASE-LR4
- Supported protocols: IEEE 802.3ba, ITU OTU4
- Data rate: 1 x 100G, Ethernet and OTU4 dual rate
- Wavelength: 1310 nm, 4 x 25G LAN-WDM lanes
- Fibre type: SMF duplex, 9-micron core per G.652
- Reach: up to 10 km, minimum 2 m
- Connector: Dual SC/PC, PC or UPC patch cords only
- Transmit power per lane: -4.3 to 4.5 dBm
- Receive power per lane: -10.6 to 4.5 dBm
- Digital Optical Monitoring: Supported
- Power consumption: less than 8.0 W maximum at 70 C
- Dimensions (H x W x D): 11.6 x 34.8 x 101.2 mm
- Weight: approx. 127 g
- Operating temperature: 0 to 70 C
- Storage temperature: -40 to 85 C
- Laser safety: Class 1
- RoHS: RoHS 6 compliant

FAQs

Q: Does this module need a licence or subscription?
A: No. The module itself needs no licence or subscription. It is powered by the host CPAK port.

Q: What fibre and connectors does it use?
A: It uses duplex single-mode fibre (9-micron, G.652) with dual SC/PC connectors. Use PC or UPC patch cords only, up to 10 km.

Q: Which platforms is it listed for?
A: The datasheet lists ASR 1000 and ASR 9000 routers, CRS-X, NCS 2000, 4000 and 6000 platforms, Nexus 7000 and 7700 switches and the Cisco ONS Transport Platform. Check the Cisco Transceiver Module Compatibility Matrix for exact platforms and software.

Q: How much power does it draw?
A: Maximum consumption is below 8.0 W at 70 C, supplied by the host CPAK port with no external power.

Q: What does the dual rate mean?
A: The module supports both 100G Ethernet and OTU4 rates, so it can be used in Ethernet and optical transport applications.
