Cisco

Cisco CPAK-100G-CWDM4 | CPAK 100G Transceiver, CWDM4, 2km SMF, Duplex LC

CPAK-100G-CWDM4

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The CPAK-100G-CWDM4 is a hot-swappable 100G CPAK optical transceiver from the Cisco CPAK 100GBASE range. It carries a 100 Gigabit Ethernet signal over four CWDM wavelengths and is built for 100G links in enterprise and service provider data centres and service provider edge networks.

This CWDM4 variant runs over a duplex single-mode fibre pair with LC connectors, reaching up to 2 km over G.652 fibre. The four lanes operate at 1271, 1291, 1311 and 1331 nm, with transmit power of -6.5 to +2.5 dBm per lane and receive power of -11.5 to +2.5 dBm per lane. Maximum power consumption is under 9.0 W at 70 C, and Digital Optical Monitoring is supported. Patch cords must be terminated with PC or UPC connectors. It is a passive optical module, so no licence or subscription is required.

It plugs into CPAK-based ports on platforms such as the ASR 9000 Series, CRS-X, NCS 2000, 4000 and 6000 Series, Nexus 7000 and 7700 Series, and the Cisco ONS Transport Platform. Check the Cisco Transceiver Module Compatibility Matrix for per-platform support.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swappable; plugs into a CPAK-based switch, router, or optical platform port
- CPAK form factor uses about 40% less power than CFP2 and 70% less than CFP
- About 20% greater port density and front-panel bandwidth than competing products
- Digital Optical Monitoring (DOM) support
- Cisco quality ID feature lets the host platform identify whether the module is certified and tested by Cisco
- Supports the Cisco AnyPort solution and a pay-as-you-grow model

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Product ID: CPAK-100G-CWDM4
- Description: 100GBASE-CWDM4 Cisco CPAK Module for SMF
- Form factor: Cisco CPAK
- Supported mode: 1x100G
- Supported protocol: 100G CWDM4 MSA
- Nominal wavelengths: 1271, 1291, 1311, 1331 nm
- Fibre type: SMF Duplex
- Core size: 9-micron core, SMF per G.652
- Cable distance: 2 km
- Connector: Dual LC (patch cords with PC or UPC connectors only)
- Transmit power (max): +2.5 dBm per lane
- Transmit power (min): -6.5 dBm per lane
- Receive power (max): +2.5 dBm per lane
- Receive power (min): -11.5 dBm per lane
- Dimensions (H x W x D): 11.6 x 34.8 x 101.2 mm
- Weight: approx. 127 g
- Power consumption: <9.0 W maximum at 70 C
- Operating temperature: 0 to 70 C (32 to 158 F)
- Storage temperature: -40 to 85 C (-40 to 185 F)

FAQs

Q: Does the CPAK-100G-CWDM4 need a licence or subscription?
A: No. It is a passive optical module, so no licence or subscription is required.

Q: How is the module powered?
A: It is powered by the host CPAK port. Maximum power consumption is under 9.0 W at 70 C.

Q: Which platforms does it work with?
A: Listed platforms include the ASR 1000 and ASR 9000 Series Routers, CRS-X, NCS 2000, 4000 and 6000 Series Routers, Nexus 7000 and 7700 Series Switches, and the Cisco ONS Transport Platform. Check the Cisco Transceiver Module Compatibility Matrix for per-platform support.

Q: What fibre and connectors does it need?
A: It needs a duplex single-mode fibre pair (G.652) with LC connectors. Use patch cords terminated with PC or UPC connectors only.

Q: How far can it reach?
A: It supports links up to 2 km over single-mode fibre.
