• Dell PowerEdge server rack with Cisco ASR1002HX IPSec crypto module
1 1

Cisco

Cisco ASR1002HX-IPSECHW | ASR 1002-HX IPsec Crypto Module, License-Activated

ASR1002HX-IPSECHW

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The ASR1002HX-IPSECHW is a field-installable hardware IPsec crypto module for the Cisco ASR 1002-HX router in the ASR 1000 Series. It offloads IPsec encryption to dedicated hardware, making it suited to site-to-site VPN, DMVPN and Easy VPN deployments at the WAN aggregation, enterprise edge, service-provider edge and internet edge.

This SKU ships with no default crypto throughput. Throughput is enabled through a software-activated licence in tiers of 8 Gbps, 16 Gbps or 25 Gbps, so capacity can be scaled without a hardware change. The 8G base licence is FLSA1-2HXIPS8G, with upgrade licences FLSA1-2HX8G16G and FLSA1-2HX8G25G available for higher tiers. Licences are offered as Right-to-Use or Permanent. The host ASR 1002-HX platform supports up to 39 Gbps of plain IPsec on its integrated ESP and up to 8,000 IPsec tunnels.

The module is designed for the ASR 1002-HX only and requires Cisco IOS XE 16.2.1S or later. It is not interchangeable with the ASR1001HX-IPSECHW module used in the ASR 1001-HX.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Offloads IPsec encryption to dedicated hardware on the ASR 1002-HX
- Throughput scales in 8G, 16G and 25G tiers through licence activation
- Supports IPsec 3DES and AES encryption
- Supports DMVPN and Easy VPN with the required RTU licensing
- Field-replaceable and upgradable module
- Suited to WAN aggregation and internet edge deployments

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: ASR1002HX-IPSECHW
- Module type: Hardware IPsec crypto module, field-upgradable
- Default crypto throughput: None, licence-activated
- Supported throughput tiers: 8 Gbps, 16 Gbps or 25 Gbps
- Compatible chassis: Cisco ASR 1002-HX Router
- Licence types: Right-to-Use or Permanent
- Base licence: FLSA1-2HXIPS8G (8G)
- Upgrade licences: FLSA1-2HX8G16G, FLSA1-2HX8G25G, L-FLSA1-2HX16G25G=
- Host platform IPsec bandwidth: up to 39 Gbps plain IPsec (1400-byte packets)
- Host platform IPsec tunnel scale: up to 8,000 tunnels
- Minimum software: Cisco IOS XE 16.2.1S or later
- Throughput check command: show platform hardware crypto-throughput level

FAQs

Q: Does this module need a licence to work?
A: Yes. It ships with no default crypto throughput, so a crypto throughput licence is required. The 8G base licence is FLSA1-2HXIPS8G, with upgrades to 16G or 25G available.

Q: What throughput levels can be enabled?
A: 8 Gbps, 16 Gbps or 25 Gbps, activated through software licences. You can verify the active level with the show platform hardware crypto-throughput level command.

Q: Which router is it compatible with?
A: It is designed for the Cisco ASR 1002-HX only and requires Cisco IOS XE 16.2.1S or later.

Q: Can I use it in an ASR 1001-HX?
A: No. The ASR 1001-HX uses a different module, ASR1001HX-IPSECHW, which supports 8G and 16G tiers only.

Q: Which IPsec features does it support?
A: IPsec 3DES and AES, DMVPN and Easy VPN, when combined with the required Right-to-Use tier-based licensing.
