• Cisco ASR1000-ESP5 Embedded Services Processor with Catalyst 3850-48P-S module
1 1

Cisco

Cisco ASR1000-ESP5 | ASR 1000 5 Gbps Embedded Services Processor, ASR1002

ASR1000-ESP5

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The ASR 1000 Embedded Services Processor (ESP5) is the 5 Gbps forwarding and services engine for the ASR 1002 chassis in the Cisco ASR 1000 Series Aggregation Services Routers. Built around the Cisco QuantumFlow Processor (QFP), it handles forwarding and services such as firewall, NAT, QoS and NetFlow. It suits branch, WAN and Internet edge aggregation, as well as enterprise or service-provider edge deployments running IPsec VPN, firewall/NAT, QoS and NetFlow.

The ESP5 provides 5 Gbps of system bandwidth and up to 4 Mpps of forwarding for the combination of IPv4 forwarding, IP multicast, ACL, QoS, reverse path forwarding, load balancing and Sampled NetFlow, depending on the features configured. It carries 256 MB of QuantumFlow Processor memory, 5 Mb of TCAM, a 64 MB packet buffer and 1 GB of FECP DRAM. Security traffic performance is 1 Gbps, with zone-based firewall and NAT services up to 5 Gbps and 250k total firewall sessions.

The module is not a standalone router. It installs in the single ESP slot of the ASR 1002 chassis, where the midplane connects it to the ASR1000-RP1 route processor, shared port adapters and power supplies. It belongs to the same ESP family as the ESP10, and features such as IPsec VPN, Firewall and FPI are enabled by feature licences on Cisco IOS XE.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Cisco QuantumFlow Processor (QFP) based forwarding engine
- Hardware-accelerated services including firewall, NAT, QoS, ACL, multicast and NetFlow
- Active and standby indication through ACTV and STBY LEDs for redundant systems
- Control processor (FECP) with dedicated DRAM on the ESP
- Midplane connection to the ASR1000-RP1 route processor, SPAs and power supplies
- Part of the Cisco ASR 1000 ESP family alongside ESP10, ESP20, ESP40, ESP100 and ESP200

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Module type: Embedded Services Processor
- System bandwidth: 5 Gbps
- Forwarding performance: up to 4 Mpps (IPv4 forwarding, IP multicast, ACL, QoS, RPF, load balancing, Sampled NetFlow, varies with features configured)
- QuantumFlow Processor memory: 256 MB
- TCAM: 5 Mb
- Packet buffer: 64 MB
- FECP DRAM: 1 GB
- Security traffic performance: 1 Gbps
- Zone-based firewall and NAT: up to 5 Gbps
- Total firewall sessions: 250k
- Supported chassis: ASR 1002 (single ESP)
- LEDs: PWR, STAT, ACTV, STBY

FAQs

Q: Which chassis does the ASR1000-ESP5 fit?
A: It is used in the Cisco ASR 1002 chassis, which has a single ESP slot. It is a module for that chassis and not a standalone router.

Q: Does the ESP5 need a separate licence?
A: No separate licence applies to the ESP5 module itself. ASR 1000 software is a Cisco IOS XE consolidated package, and features such as IPsec VPN, Firewall and FPI are enabled by feature licences.

Q: What does it work with in the ASR 1002?
A: The midplane connects the ESP5 to the ASR1000-RP1 route processor, shared port adapters and power supplies. The ASR1002-5G bundles pair it with an ASR1000-RP1 and SIP10.

Q: How much power does the ESP5 draw?
A: It is powered from the ASR 1002 chassis. The ASR 1000 chassis hardware installation guide lists maximum system power consumption of 1020 W DC and 960 W AC.

Q: How does the ESP5 differ from the ESP10?
A: Both are in the same ASR 1000 ESP family. The ESP5 provides 5 Gbps of system bandwidth, while the ESP10 is a higher-bandwidth processor in the same family.
