• Cisco AIR-ANT5959 2.4 GHz omni antenna with RP-TNC connectors
1 1

Cisco

Cisco AIR-ANT5959 | Aironet 2.4 GHz 2 dBi Diversity Omni Antenna, RP-TNC

AIR-ANT5959

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Cisco Aironet AIR-ANT5959 is a 2.4 GHz diversity omnidirectional antenna designed for indoor ceiling mounting. It suits indoor office environments that need a low-profile, unobtrusive antenna for 802.11b/g/n coverage, and it connects to Cisco Aironet radios through RP-TNC connectors.

It carries two separate omnidirectional elements, each rated at 2 dBi nominal gain (minimum 2.0 dBi, maximum 2.35 dBi), which supports antenna diversity across the 2400-2500 MHz band. The connectors are RP-TNC male. It is a passive antenna and requires no power. It measures 13.5 x 7.1 x 2.3 cm and weighs 0.14 kg, so it is light and slim enough to sit discreetly on a ceiling.

This antenna works with Cisco Aironet access points and radios that use RP-TNC antenna connectors on the 2.4 GHz band, including 1130 Series access points. It is also the Cisco-listed replacement for older ceiling antennas such as AIR-ANT3194 and AIR-ANT2561.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Unobtrusive ceiling-mount design for indoor offices
- Two antenna elements support antenna diversity
- Omnidirectional coverage on the 2.4 GHz band
- RP-TNC male connectors for Cisco Aironet radios
- Passive design with no power requirement
- Lightweight, low-profile housing
- Replacement for older ceiling antennas such as AIR-ANT3194 and AIR-ANT2561

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Frequency range: 2400 - 2500 MHz (2.4 GHz, 802.11b/g/n)
- Antenna type: Diversity omnidirectional, ceiling mount
- Gain: Two separate 2 dBi omnidirectional elements
- Gain range: minimum 2.0 dBi, maximum 2.35 dBi
- Connector type: RP-TNC Male
- Environment: Indoor, office environment
- Power: Passive antenna, requires no power
- Dimensions (L x W x H): 13.5 x 7.1 x 2.3 cm (5.3 x 2.8 x 0.9 in)
- Weight: 0.14 kg (0.3 lbs)

FAQs

Q: Does this antenna need power?
A: No. It is a passive antenna and requires no power. It draws everything it needs through the radio connection.

Q: Which access points does it work with?
A: It works with Cisco Aironet access points and radios that use RP-TNC antenna connectors on the 2.4 GHz band, including 1130 Series access points.

Q: Can it be used on the 5 GHz band?
A: No. It operates across 2400-2500 MHz only, so it covers the 2.4 GHz band for 802.11b/g/n.

Q: Is it suitable for outdoor use?
A: No. It is designed for indoor ceiling mounting in office environments.

Q: Which older antennas does it replace?
A: Cisco lists it as the replacement for older ceiling antennas such as AIR-ANT3194 and AIR-ANT2561.
