• Cisco AIR-ANT5117S-N 5 GHz 17 dBi sector antenna with N-female connector
1 1

Cisco

Cisco AIR-ANT5117S-N | Aironet 5 GHz 17 dBi 90-Degree Sector Antenna, N-Female

AIR-ANT5117S-N

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Aironet 5 GHz 17 dBi sector antenna is a passive outdoor antenna built for point-to-multipoint wireless deployments. It suits Cisco 5 GHz bridges and access points that use a standard N-connector, and is typically mounted on a mast to provide sector coverage for outdoor links.

It covers 4900 to 5850 MHz with 16.5 dBi of measured gain, marketed as 17 dBi. The beam is 90 degrees in azimuth and 5.5 degrees in elevation, with vertical polarisation and a 50 ohm nominal input impedance. Connection is through a standard N-female connector, and the antenna requires no power.

The housing measures 24.7 in. by 2.75 in. by 1-7/8 in. and weighs 2 lbs (0.9 kg). It is rated for operation from -40 to 85 C and for a wind rating of 125 mph. Mounting brackets suit masts from 1.5 in. to 3.5 in. (3.8 to 8.9 cm) in diameter. Keep the cable run short and use high-quality, low-loss cable, and seal outdoor connections with coax seal.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Operates across the 4.9 to 5.85 GHz range
- Designed for point-to-multipoint environments
- Built for outdoor use with a 125 mph wind rating
- Mast mounting with brackets for 1.5 to 3.5 in. diameter masts
- Standard N-female connector for low-loss coaxial cable
- Passive design, no power required

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Antenna type: 90-degree sector
- Operating frequency range: 4900 - 5850 MHz
- Gain: 16.5 dBi (marketed as 17 dBi)
- Polarisation: Vertical
- Azimuth 3-dB beamwidth: 90 degrees
- Elevation 3-dB beamwidth: 5.5 degrees
- Nominal input impedance: 50 ohm
- 2:1 VSWR bandwidth: 4900 - 5850 MHz
- Connector: Standard N-female
- Length: 24.7 in. (62.74 cm)
- Width: 2.75 in. (7 cm)
- Depth: 1-7/8 in. (4.76 cm)
- Weight: 2 lbs (0.9 kg)
- Operating temperature: -40 to 185 F (-40 to 85 C)
- Wind rating: 125 mph (201 km/h)
- Mast mounting: 1.5 in. to 3.5 in. (3.8 to 8.9 cm) diameter masts

FAQs

Q: Does this antenna need power?
A: No. It is a passive antenna and requires no power supply.

Q: What devices does it work with?
A: It is designed for Cisco 5 GHz bridges and access points that use a standard N-connector. The mating connector on the cable is an N-type jack.

Q: What mast sizes can it be mounted on?
A: The supplied mounting brackets fit masts from 1.5 in. to 3.5 in. (3.8 to 8.9 cm) in diameter.

Q: What cable should I use?
A: Use high-quality, low-loss coaxial cable kept as short as possible, and seal outdoor connections with coax seal.

Q: What coverage pattern does it provide?
A: It has a 90-degree azimuth beamwidth and a 5.5-degree elevation beamwidth with vertical polarisation, suited to sector coverage in point-to-multipoint links.
