Cisco

Cisco AIR-ANT3213 | Aironet 2.4 GHz 5.2 dBi Pillar-Mount Omni Antenna

AIR-ANT3213

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Aironet AIR-ANT3213 is an indoor 2.4 GHz diversity omnidirectional antenna designed for pillar mounting. Its unobtrusive tan cloth covering suits retail stores, hospitals and open areas with pillars, where a low-profile antenna is preferred over a visible rod or panel.

It uses two radiating elements with 5.2 dBi gain and vertical polarisation, giving 360 degree azimuth coverage in the 2.4 to 2.5 GHz band. Two RP-TNC connectors terminate a 36 in white RG58 cable, with a 10 in separation between the two coax runs to support diversity operation. It is a passive antenna and needs no power.

Two mounting brackets hold the antenna about 6 in (15 cm) off a pillar or wall, and the mount allows the antenna to be angled to optimise the beam. It is intended for Cisco Aironet access points and bridges with RP-TNC antenna connectors in the 2.4 GHz band, and is for indoor use only.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Unobtrusive cosmetic design with a tan cloth covering
- Diversity design with two radiating elements and two RP-TNC cables
- Two brackets allow mounting on a pillar or wall, spaced about 6 in from the surface
- Mount allows the antenna to be angled to optimise the beam
- 360 degree omnidirectional azimuth coverage with vertical polarisation
- Suited to retail and hospital environments

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Antenna type: Pillar-mount diversity omnidirectional, two radiating elements
- Frequency range: 2.4 GHz (2.4-2.5 GHz band)
- Gain: 5.2 dBi
- Polarisation: Vertical
- Azimuth beamwidth (3 dB): Omnidirectional, 360 degrees
- Antenna connector: Two RP-TNC
- Cable: 36 in (approx. 0.9 m) white RG58, with 10 in separation between the two coax runs
- Dimensions (approx.): 12 x 5 x 1 in (30.5 x 12.7 x 2.5 cm)
- Weight: 5.3 oz (150 g)
- Approx. indoor range at 11 Mbps: 142 ft (44 m)
- Approx. indoor range at 6 Mbps: 507 ft (155 m)
- Approx. indoor range at 1 Mbps: 542 ft (165 m)
- Environment: Indoor only
- Mounting: Pillar mount with two brackets, about 6 in (15 cm) off the pillar or wall
- Appearance: Tan cloth covering, cosmetic antenna
- Power: Passive antenna, no power required

FAQs

Q: Does this antenna need power?
A: No. It is a passive antenna and requires no power. It connects to the access point through its two RP-TNC cables.

Q: Which access points does it work with?
A: It is designed for Cisco Aironet access points and bridges with RP-TNC antenna connectors in the 2.4 GHz band. Confirm the connector type and band on your access point before ordering.

Q: Can it be used outdoors?
A: No. The AIR-ANT3213 is designed for indoor use only.

Q: How is it mounted?
A: It uses two mounting brackets to fix to a pillar or wall, holding the antenna about 6 in (15 cm) off the surface. The mount allows the antenna to be angled to optimise the beam.

Q: Does it support 5 GHz?
A: No. It operates in the 2.4 GHz band only (2.4 to 2.5 GHz). A separate 5 GHz antenna is needed for 5 GHz radios.
